Установкa Thermo King Super NWD 5200 схема ELECTRICAL COMPONENTS (NWD 30) – 45E9
Обновление от: 6/18/97
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 66-2020 | SWITCH - air (see 43C6) | 1 | |
|
P-12-01039-08 | Выключатель размораживания, Maxima/Supra/ Vector 1350/1550/18XX/19XX | 16 490 ₽ |
|
| 2 | 44-2823 | SOLENOID (see 95F3) | 1 | |
|
10-44-2823 | Соленоид оборотов двигателя | 5 370 ₽ |
|
| 3 | 44-3155 | SWITCH - defrost termination | 2 | |
|
10-44-3155 | Выключатель оттайки, KD/MD/RD-I / SB-I/II | 4 780 ₽ |
|
| 4 | 44-6198 | HARNESS - evaporator | 1 | |
| 5 | 44-5565 | HARNESS - main | 1 | |
| 6 | 44-5214 | SOCKET (12-pin) | 1 | |
| 44-5220 | COVER - socket | 1 | ||
| 7 | 44-4925 | CONNECTOR - remote lights | 1 | |
| 8 | 44-5030 | CONNECTOR - thermostat | 1 | |
| 9 | 44-5218 | CONNECTOR - evaporator section | 1 | |
| 10 | 44-5219 | CONNECTOR - hpco switch | 1 | |
| 33-1661 | GROMMET | 1 | ||
| 11 | 44-3018 | SWITCH - water temperature | 1 | |
|
10-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 5 830 ₽ |
|
| PP-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 2 200 ₽ |
|
|
| 55-2116 | BUSHING - switch | 1 | ||
| 12 | 44-3325 | ALTERNATOR (see 20C9) | 1 | |
| US-44-3325 | Генератор 35A/12V | 35 130 ₽ |
|
|
|
10-44-3325 | Генератор 35A/12V | 28 440 ₽ |
|
| 13 | 44-5013 | REGULATOR - voltage | 1 | |
| 44-5013 OEM | Реле-регулятор генератора, KD/MD/RD-I / SB-I/II / UMD/URD | 5 050 ₽ |
|
|
| 14 | 44-5014 | HARNESS - voltage regulator | 1 | |
|
10-44-5014 | Проводка генератора | 3 820 ₽ |
|
| 55-2991 | SCREW - regulator | 3 | ||
| 55-2001 | FLATWASHER | 6 | ||
| 55-1511 | LOCKWASHER | 3 | ||
| 55-2752 | NUT | 3 | ||
| 15 | 45-252 | PANEL - switch (see 51B9) | 1 | |
| 16 | 66-1155 | THERMOSTAT (U.E.) | 1 | |
| 45-1564 | THERMOSTAT (TG) | 1 | ||
| 99-6484 | BRACKET - thermo bulb | 1 | ||
| 55-3484 | CLAMP (0.312 dia) | 2 | ||
| 55-547 | CLAMP (0.375 dia) | 1 | ||
| 55-3227 | SCREW - clamp | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2965 | NUT | 2 | ||
| 17 | 44-5180 | HARNESS - thermostat | 1 | |
| 44-5214 | SOCKET (12-pin) | 1 | ||
| 44-2825 | COVER - socket | 1 | ||
| 44-4925 | CONNECTOR | 1 | ||
| 18 | 44-6011 | HARNESS - thermostat (TG, see 53D11) | 1 | |
| 44-5310 | CONNECTOR (15-pin) | 1 | ||
| 44-2825 | COVER - socket | 1 | ||
| 44-4925 | CONNECTOR | 1 | ||
| 44-3190 | CONNECTOR | 1 | ||
| 55-2263 | SCREW - thermostat | 3 | ||
| 99-5635 | COVER - thermostat | 1 | ||
| 33-1363 | GASKET - cover | 1 | ||
| 55-1049 | SCREW - cover | 3 | ||
| 55-431 | FLATWASHER | 6 | ||
| 55-1511 | LOCKWASHER | 3 | ||
| 55-2752 | NUT | 3 | ||
| 19 | 44-5217 | HARNESS - indicator light (see 42B6) | 1 | |
| 20 | 44-4774 | SWITCH - oil pressure | 1 | |
|
10-44-4774 | Выключатель давления масла | 5 530 ₽ |
|
| 21 | 44-4582 | TERMINAL - battery (see 16D2) | 1 | |
| 22 | 44-5305 | SWITCH - hpco (R12) | 1 | |
|
10-44-5305 | Выключатель высокого давления (R12) | 3 950 ₽ |
|
| 44-5508 | SWITCH - hpco (R502) | 1 | ||
|
10-44-5508 | Выключатель высокого давления (R502) | 8 490 ₽ |
|
| 23 | 44-2922 | GLOW PLUG | 4 | |
|
10-44-2922 | Свеча накаливания, Isuzu C201 | 1 510 ₽ |
|
| 24 | 66-2009 | VALVE - pilot solenoid | 1 | |
|
10-66-2009 | Управляющий клапан, KD/MD/TD/RD-II / SB-I/II/III | 18 500 ₽ |
|
| 44-3803 | COIL - valve | 1 | ||
| 55-8786 | NUT - valve | 1 |
