Установкa Thermo King Super-II Tier 2 Engine (701297) схема MUFFLER GROUP – 149C7
Обновление от: 1/15/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 12-763 | MUFFLER | 1 | |
| 12-568 | MUFFLER (stainless steel) | 1 | ||
| 55-3018 | SCREW - muffler | 2 | ||
|
20-55-3018 | Болт | 540 ₽ |
|
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 2 | 91-3896 | CLAMP - muffler | 1 | |
| 203-453 | SEALER - exhaust system | A/R | ||
| 3 | 91-5697 | TUBE - exhaust | 1 | |
| 4 | 55-6861 | CLAMP - tube | 1 | |
| 55-140 | SCREW - clamp | 1 | ||
| 55-411 | FLATWASHER | 2 | ||
| 55-4118 | NUT | 1 | ||
| 5 | 33-2314 | GASKET - flange | 1 | |
| 33-2314 OEM | Прокладка глушителя, Isuzu 2.2 DI (D201), Yanmar 482 / 486 / 486V | 1 250 ₽ |
|
|
|
10-33-2314 | Прокладка глушителя, Isuzu 2.2 DI (D201), Yanmar 482 / 486 / 486V | 990 ₽ |
|
|
PP-33-2314 | Прокладка глушителя, Isuzu 2.2 DI (D201), Yanmar 482 / 486 / 486V | 480 ₽ |
|
| 6 | 55-5406 | SCREW - flange | 2 | |
| 55-790 | LOCKWASHER | 2 | ||
| 7 | 55-4621 | NUT | 2 | |
| 8 | 91-7187 | SHIELD - manifold | 1 | |
| 55-4998 | SCREW - shield | 3 | ||
| 55-790 | LOCKWASHER | 3 | ||
| 55-4613 | FLATWASHER | 3 | ||
| 9 | 91-4771 | SHIELD - heat | 1 | |
| 55-2306 | SCREW - shield | 3 | ||
| 30-55-2306 | Болт 3/8x1 5/8 | 680 ₽ |
|
|
| 10 | 91-4772 | CLAMP - heat shield (rear) | 1 | |
| 11 | 91-4773 | CLAMP - heat shield (front) | 1 | |
| 12 | 55-3018 | SCREW - clamp | 2 | |
|
|
20-55-3018 | Болт | 540 ₽ |
|
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 |
