Установкa Thermo King Super-II ThermoFresh w/di 2.2 Engine схема COOLING SYSTEM – 91B2
Обновление от: 7/28/00
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1328 | TANK - accumulator (R12/R502, convertible) | 1 | |
| 2 | 91-745 | BRACKET - accumulator | 1 | |
| 55-2969 | SCREW - bracket | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 55-371 | FLATWASHER | 2 | ||
| 3 | 91-746 | BRACKET - radiator support | 1 | |
| 55-529 | SCREW - bracket | 2 | ||
| 55-375 | LOCKWASHER | 2 | ||
| 55-402 | FLATWASHER | 2 | ||
| 4 | 12-760 | RADIATOR | 1 | |
| 12-761 | RADIATOR (vinyl dipped, optional) | 1 | ||
| 99-9894 | NUTSTRIP - radiator | 3 | ||
| 55-1725 | RIVET - nutstrip | 6 | ||
| 55-2969 | SCREW - radiator | 6 | ||
| 55-790 | LOCKWASHER | 6 | ||
| 55-371 | FLATWASHER | 4 | ||
| 55-2904 | WASHER - special | 2 | ||
| 5 | 98-3283 | PANEL - radiator cover | 1 | |
| 55-2969 | SCREW - panel (1.0 lg) | 2 | ||
| 55-139 | SCREW - panel (1.5 lg) | 1 | ||
| 55-2958 | FLATWASHER | 3 | ||
| 55-4954 | NUT | 3 | ||
| 6 | 33-1824 | STRIP - sealing | 1 | |
| 7 | 11-6305 | TUBE - radiator to expansion tank (before 5/91) | 1 | |
| 11-7299 | TUBE - radiator to expansion tank (after 5/91) | 1 | ||
| 8 | 33-287 | GROMMET | 1 | |
| 9 | 55-2536 | CLAMP - tube | 1 | |
| 10 | 11-5406 | CAP - radiator | 1 | |
|
10-11-5406 | Крышка радиатора | 2 200 ₽ |
|
| 12-506 | TANK - expansion (before 5/91) | 1 | ||
| 11 | 10-345 | KIT - tank, expansion | 1 | |
| 55-2796 | CLAMP - fuel line | 2 | ||
| 11-4677 | HOSE | 1 | ||
| 81-293 | FITTING - barb | 1 | ||
| 55-2539 | BUSHING | 1 | ||
| 12-777 | TANK - expansion | 1 | ||
| 55-1587 | SCREW - tank | 3 | ||
| 55-1201 | WASHER - special | 3 | ||
| 55-2086 | FLATWASHER | 3 | ||
| 55-4953 | NUT | 3 | ||
| 12 | 44-6534 | SENSOR - coolant level | 1 | |
|
10-44-6534 | Сенсор радиатора | 8 830 ₽ |
|
| 13 | 99-1665 | HOSE - overflow (90.0 lg) | A/R | |
| 91-2670 | BRACKET - tank (after 5/91) | 1 | ||
| 14 | 11-6306 | TUBE - expansion tank to engine (before 5/91) | 1 | |
| 11-7300 | HOSE - engine to expansion tank (after 5/91) | 1 | ||
| 55-4203 | CLAMP - tube | 1 | ||
| 55-558 | CLAMP - hose | 1 | ||
| 15 | 11-7377 | HOSE - engine outlet (neoprene) | 1 | |
| 11-7378 | HOSE - silicone | 1 | ||
| 16 | 11-6301 | TUBE - engine inlet (neoprene) | 1 | |
| 11-6336 | HOSE - silicone | 1 | ||
| 17 | 55-558 | CLAMP - hose (neoprene) | 4 | |
| 55-3402 | CLAMP - hose (silicone) | 4 | ||
| 18 | 11-6303 | TUBE - engine outlet | 1 | |
| 19 | 55-6013 | TEE | 1 | |
| 20 | 99-3884 | CLAMP - tube | 1 | |
| 55-1587 | SCREW - clamp | 1 | ||
| 55-2086 | FLATWASHER | 1 | ||
| 21 | 11-6302 | TUBE - radiator outlet | 1 | |
| 22 | 11-6300 | TUBE - radiator inlet | 1 | |
| 23 | 55-1521 | CLAMP - hose | 4 | |
| 24 | 98-796 | HOSE (neoprene, cut to 47 in) | A/R | |
| 12-383 | HOSE (silicone) | A/R | ||
| 25 | 91-1785 | BRACKET - hose (curbside, see 90G6) | 1 | |
| 91-1783 | BRACKET - hose (roadside, see 90G6) | 1 | ||
| 26 | 55-3359 | CLAMP - hose | 6 | |
| 27 | 11-6308 | FITTING - hose | 1 | |
| 28 | 55-1592 | CONNECTOR - hose | 1 | |
| 29 | 55-6015 | ELBOW (45) | 1 | |
| 30 | 55-2523 | ELBOW (90) | 1 | |
| 31 | 11-3346 | ADAPTER - thermostat housing | 1 | |
| 55-5424 | SCREW - adapter | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 32 | 11-7702 | THERMOSTAT | 1 | |
|
11-7702 OEM | Термостат Isuzu 2.2, SB-I/II/III / SMX/SMX-II | 3 830 ₽ |
|
|
10-11-7702 | Термостат Isuzu 2.2, SB-I/II/III / SMX/SMX-II | 1 790 ₽ |
|
| 33 | 33-487 | GASKET | 1 | |
|
10-33-487 | Прокладка термостата, Isuzu 2.2, SB-I/II/III / SMX/SMX-II | 910 ₽ |
|
| 34 | 55-5094 | DRAIN COCK | 1 | |
| 35 | 33-1887 | GASKET - sealing | 1 | |
| 36 | 10-253 | KIT - fuel heater | 1 |
