Установкa Thermo King ShuttleAIRE Series Bus схема REFRIGERATION CONDENSER (S-20 II, S-30 II, S-40 II) – 133F10
Обновление от: 4/9/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1350 | COIL - condenser (S-20 II) | 1 | |
| 67-1359 | COIL - condenser (S-30 II) | 1 | ||
| 67-1358 | COIL - condenser (S-40 II) | 1 | ||
| 2 | 66-4139 | FITTING - saddle | 1 | |
| 3 | 66-8342 | TUBE - outlet | 1 | |
| 4 | 66-8343 | TUBE - inlet | 1 | |
| 5 | 55-6838 | NUT (o-ring seal) | 1 | |
| 6 | 55-6837 | SHOULDER | 1 | |
| 7 | 66-8344 | DEHYDRATOR | 1 | |
| 8 | 33-2350 | O-RING | 2 | |
| 9 | 55-7800 | CLAMP - dehydrator | 1 | |
| 10 | 55-8691 | ADAPTER (o-ring seal) | 1 | |
| 11 | 91-7507 | BRACKET - adapter | 1 | |
| 55-2260 | RIVET - blind | 2 | ||
| 12 | 67-1351 | TANK - receiver | 1 | |
| 13 | 41-1502 | SWITCH - hpco (after 1/97) | 1 | |
| 13 | 41-2588 | SWITCH - pressure modulation | 1 |
