Установкa Thermo King ShuttleAIRE S-45 схема HOSE & FITTING KITS (718841, 718843) – 227H1
Обновление от: 1/3/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR - TM31 (see 184G8) | 1 | |
| 2 | 61-671 | FITTING - elbow (45 deg) | 1 | |
| 33-2847 | O-RING (11/16 id) | 2 | ||
| 3 | 61-2500 | HOSE - discharge (#12) | A/R | |
| 4 | 61-668 | FITTING - straight | 1 | |
| 5 | 61-667 | FITTING - straight | 1 | |
| 6 | 61-4308 | HOSE - liquid (#8) | A/R | |
| 7 | 61-660 | FITTING - straight | 1 | |
| 8 | 55-9790 | FITTING - manuli, straight | 2 | |
| 33-2847 | O-RING (11/16 id) | 2 | ||
| 9 | 61-2152 | HOSE - suction (#16) | A/R |
