Установкa Thermo King ShuttleAIRE S-40 схема ShuttleAIRE S-40 REFERENCE SHEET – 8U16
Обновление от: 8/17/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 919058 | System - S-40 1000, 12 V | 10/02 | ||
| 919059 | System - S-40 1000, 24 V | 10/02 | ||
| 919060 | System - S-40 1004, 12 V | 10/02 | ||
| 919061 | System - S-40 1004, 24 V | 10/02 | ||
| 006792 | S-40 U Undermount Condenser w/o Harness, 12 V | 1/08 | ||
| 006798 | S-40 R Rooftop condenser w/o Harness, 12 V | 1/08 | ||
| 006793 | S-40 U Undermount Condenser w/o Harness, 24 V | 1/08 | ||
| 006799 | S-40 R Rooftop Condenser w/o Harness, 24 V | 1/08 | ||
| 700070 | Harness Kit - Condenser to CP (13 m, 12 V) | 1/08 | ||
| 700071 | Harness Kit - Condenser to CP (15 m, 12 V) | 1/08 | ||
| 700072 | Harness Kit - Condenser to CP (13 m, 24 V) | 1/08 | ||
| 700074 | Harness Kit - Condenser to CP (15 m, 24 V) | 1/08 | ||
| 099552 | S-30 1000 Evaporator Assembly, 12 V | 10/02 | ||
| 099553 | S-30 1000 Evaporator Assembly, 24 V | 10/02 | ||
| 099554 | S-30 1004 Evaporator / Heater Assembly, 12 V | 10/02 | ||
| 099555 | S-30 1004 Evaporator / Heater Assembly, 24 V | 10/02 | ||
| 720819 | Kit - Control Panel S20/30/40, 12 V | 1/08 | ||
| 720820 | Kit - Control Panel S20/30/40, 24 V | 1/08 | ||
| 720839 | Harness Kit - CP to Compressor (10 m) | 1/08 | ||
| 720849 | Harness Kit - CP to Compressor (18 m) | 1/08 | ||
| 720713 | ClimaAIRE I DP | 1/08 | ||
| 700993 | ClimaAIRE I D DP | 1/08 | ||
| 720827 | Harness Kit - CP to DP CA I (3 m) | 1/08 | ||
| 720828 | Harness Kit - CP to DP CA I (10 m) | 1/08 | ||
| 720829 | Harness Kit - CP to DP CA I (14 m) | 1/08 | ||
| 720714 | ClimaAIRE II DP | 1/08 | ||
| 880114 | Kit - Ambient Sensor CA II (9 m) | 1/08 | ||
| 720830 | Harness Kit - CP to DP CA II (3 m) | 1/08 | ||
| 720831 | Harness Kit - CP to DP CA II (10 m) | 1/08 | ||
| 720832 | Harness Kit - CP to DP CA II (14 m) | 1/08 | ||
| 718370 | Compressor Kit - TM16, Double A Pulley 12 V, POE Oil, no Manifold | 10/02 | ||
| 718372 | Compressor Kit - TM16, Polygroove Pulley, 12 V, POE Oil, no Manifold | 10/02 | ||
| 718371 | Compressor Kit - TM16, Double A Pulley 24 V, POE Oil, no Manifold | 10/02 | ||
| 718373 | Compressor Kit - TM16, Polygroove Pulley, 24 V, POE Oil, no Manifold | 10/02 | ||
| 720286 | Compressor Kit - TM21, 12 V, 1B Pulley, POE Oil | 1/08 | ||
| 720287 | Compressor Kit - TM21, 24 V, 1B Pulley, POE Oil | 1/08 | ||
| 720288 | Compressor Kit - TM21, 12 V, 2A Pulley, POE Oil | 1/08 | ||
| 720289 | Compressor Kit - TM21, 24 V, 2A Pulley, POE Oil | 1/08 | ||
| 720290 | Compressor Kit - TM21, 12 V, Polygroove Pulley, POE Oil | 1/08 | ||
| 720291 | Compressor Kit - TM21, 24 V, Polygroove Pulley, POE Oil | 1/08 | ||
| 718376 | Compressor Kit - TM31, 12 V, 2B Pulley, POE Oil | 10/02 | ||
| 718377 | Compressor Kit - TM31, 24 V, 2B Pulley, POE Oil | 10/02 | ||
| 719717 | Compressor Kit - TM31, 12 V, 2A Pulley, POE Oil | 10/02 | ||
| 719718 | Compressor Kit - TM31, 24 V, 2A Pulley, POE Oil | 10/02 | ||
| 719221 | Compressor Kit - TM31, 12 V, Polygroove Pulley, POE Oil | 10/02 | ||
| 719222 | Compressor Kit - TM31, 24 V, Polygroove Pulley, POE Oil | 10/02 | ||
| 718378 | Oil Kit - POE for TM Compressors (8 oz / 0,24 liter can) | 10/02 | ||
| 718121 | Compressor Manifold Kit - Horizontal | 10/02 | ||
| 715717 | Compressor Manifold Kit - Vertical | 10/02 | ||
| 815146 | Installation Kit - Basic | 10/02 | ||
| 720836 | Harness Kit - Extension Evaporator to CP (5 m) | 1/08 | ||
| 040611 | S-40 Evaporator Cover | 10/02 | ||
| 040850 | Plenum S-40 | 10/02 | ||
| 719052 | Kit Water valve 12Vdc, DN16mm | 10/02 | ||
| 719053 | Water Valve Kit - 27 VDC, DN 16 mm | 10/02 | ||
| 719054 | Water Pump Kit - 12 VDC, Hose 16 mm ID, 500 l/Hr | 10/02 | ||
| 719055 | Water Pump Kit - 27 VDC, Hose 16 mm ID, 500 l/Hr | 10/02 | ||
| 719700 | Harness Kit - Remote Water Valve and Pump (10 m) | 10/02 | ||
| 718128 | Fitting Kit - for TM16 Compressor, Manuli | 10/02 | ||
| 718288 | Fitting Kit - Low Profile Condenser | 10/02 | ||
| 718394 | Hose Kit - S-30/S-40 Undermount, Manuli (Lengths: S - 13,5 m, D - 7,5 m, L - 10 m) | 10/02 | ||
| 718396 | Hose Kit - S-30/S-40 Rooftop, Manuli (Lengths: S - 13,5 m, D - 16 m, L - 3,5 m) | 10/02 | ||
| 718129 | Hose Kit - Manuli (#08, bulk 82Ft length 25m) | 10/02 | ||
| 718280 | Hose Kit - Manuli (#10, bulk 82Ft length 25m) | 10/02 | ||
| 718281 | Hose Kit - Manuli (#12, bulk 82Ft length 25m) | 10/02 | ||
| 719702 | Fitting Kit - for TM16, 90 deg, EZ Clip | 10/02 | ||
| 719741 | Fitting Kit - for TM16, 45 deg, EZ Clip | 10/02 | ||
| 719742 | Fitting Kit - for TM16, straight, EZ Clip | 10/02 | ||
| 719704 | Hose Kit - S-30/S-40 Undermount, THERMO KING 2000 (Lengths: S - 13,5 m, D - 7,5 m, L - 10 m) | 10/02 | ||
| 719706 | Hose Kit - S-30/S-40 Rooftop, THERMO KING 2000 (Lengths: S - 13,5 m, D - 16 m, L - 3,5 m) | 10/02 |
