Установкa Thermo King ShuttleAIRE S-30 схема COMPRESSOR & HOSE KITS – 227G3
Обновление от: 1/3/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR - TM16 (see 179A7) | 1 | |
| NSS | COMPRESSOR - TM21 (see 184E4) | 1 | ||
| NSS | COMPRESSOR - TM31 (see 184G8) | 1 | ||
| 2 | 61-658 | FITTING - elbow (#10, Kit 718128 & 718288) | 1 | |
| 61-665 | FITTING - elbow (#10, Kit 718390) | 1 | ||
| 3 | 61-2499 | HOSE - discharge (#10) | A/R | |
| 4 | 61-663 | FITTING - w/ charge valve (#10, Kit 718128 & 718288) | 1 | |
| 5 | 61-658 | FITTING - elbow (#10) | 1 | |
| 6 | 61-662 | FITTING - elbow (#8) | 1 | |
| 7 | 61-4308 | HOSE - liquid (#8) | A/R | |
| 8 | 61-660 | FITTING - straight (#8) | 1 | |
| 9 | 61-661 | FITTING - straight (#12) | 1 | |
| 10 | 61-2500 | HOSE - suction (#12) | A/R | |
| 11 | 61-664 | FITTING - w/ charge valve (#12, Kit 718128 & 718288) | 1 | |
| 12 | 61-659 | FITTING - elbow (#12, Kit 718128 & 718288) | 1 | |
| 61-666 | FITTING - elbow (#12, Kit 718390) | 1 |
