Установкa Thermo King Sentry di EMEIA схема GAUGE PANEL – 68F4
Обновление от: 3/20/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 99-7277 | PANEL - gauge | 1 | |
| 2 | 99-7276 | NAMEPLATE - gauge | 1 | |
| 3 | 44-7485 | GAUGE - oil pressure | 1 | |
|
10-44-7485 | Датчик давления масла | 4 800 ₽ |
|
| 4 | 55-328 | ELBOW - gauge | 1 | |
| 11-5607 | ELBOW - hose | 1 | ||
| 10-242 | KIT - sleeve & eyelet (3/8) | 1 | ||
|
P-40-00342-02 | Фитинг топливной магистрали | 1 040 ₽ |
|
| 11-4941 | NUT (3/8) | 1 | ||
| 5 | 61-3467 | THERMOMETER - analog | 1 | |
|
10-61-3467 | Термометр | 15 250 ₽ |
|
| 66-3122 | LENS - thermometer | 1 | ||
| 33-1339 | GASKET - lens | 1 | ||
| 41-2590 | THERMOMETER - digital LED (F) | 1 | ||
| 44-5234 | SENSOR (10 ft) | 1 | ||
|
10-44-5234 | Сенсор | 14 130 ₽ |
|
| 44-8045 | THERMOMETER - digital (optional) | 1 | ||
| 44-5234 | SENSOR | 1 | ||
|
|
10-44-5234 | Сенсор | 14 130 ₽ |
|
| 55-3513 | SCREW - thermometer | 3 | ||
| 55-2999 | NUT | 3 | ||
| 55-3013 | FLATWASHER | 3 | ||
| 6 | 66-527 | GAUGE - compound pressure (R12) | 1 | |
|
10-66-527 | Датчик давления | 5 990 ₽ |
|
| 66-1587 | GAUGE - compound (R502) | 1 | ||
| 66-1891 | TUBE - gauge to pilot solenoid | 1 | ||
| 55-2272 | CLAMP - tube | 3 | ||
| 55-531 | SCREW | 3 | ||
| 7 | 44-8764 | HOURMETER | 1 | |
|
10-44-8764 | Счетчик часов | 7 260 ₽ |
|
| 44-7314 | HOURMETER (digital, optional) | 1 | ||
| 8 | 44-7486 | GAUGE - water temperature | 1 | |
| 55-6547 | BUSHING | 1 | ||
| 9 | 55-3571 | NUT - blind | 4 | |
| 10 | 55-2991 | SCREW - panel | 4 | |
| 55-2001 | FLATWASHER | 4 |
