Установкa Thermo King Sentry MAX w/di 2.2 Engine схема ALTERNATOR GROUP – 96A7
Обновление от: 11/28/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 45-2254 | ALTERNATOR (37 amp, see 208F4) | 1 | |
|
10-45-2589 | Генератор 37A, SB-XXX/SMX/SMX-II/SL/SLe SB-II/III | 13 870 ₽ |
|
|
10-41-6780 | Генератор 37A, SB-XXX/SMX/SMX-II/SL/SLe SB-II/III | 13 870 ₽ |
|
| 41-8461 | ALTERNATOR (37 amp, Standard Life Plus) | 1 | ||
|
|
10-45-2589 | Генератор 37A, SB-XXX/SMX/SMX-II/SL/SLe SB-II/III | 13 870 ₽ |
|
|
|
10-41-6780 | Генератор 37A, SB-XXX/SMX/SMX-II/SL/SLe SB-II/III | 13 870 ₽ |
|
| 845-2254 | ALTERNATOR (37 amp, remanufactured) | 1 | ||
| 845-2254 | ALTERNATOR (37 amp, remanufactured) | 1 | ||
| 45-2256 | ALTERNATOR (65 amp, see 242F5) | 1 | ||
|
10-45-2590 | Генератор 65A, UT800/1200 | 13 870 ₽ |
|
|
10-41-6781 | Генератор 65A, SB-XXX/SMX/SMX-II/SL/SLe/SLX/SLXe SB-II/III | 13 840 ₽ |
|
| 41-8463 | ALTERNATOR (65 amp, Standard Life Plus, CW) | 1 | ||
|
|
10-45-2590 | Генератор 65A, UT800/1200 | 13 870 ₽ |
|
|
|
10-41-6781 | Генератор 65A, SB-XXX/SMX/SMX-II/SL/SLe/SLX/SLXe SB-II/III | 13 840 ₽ |
|
| 845-2256 | ALTERNATOR (65 amp remanufactured) | 1 | ||
| 55-6961 | SPACER - alternator | 1 | ||
| 2 | 77-2022 | PULLEY - alternator | 1 | |
| 3 | 91-9771 | BRACKET - alternator | 1 | |
| 4 | 55-2038 | FLATWASHER | 1 | |
| 5 | 55-365 | LOCKWASHER | 1 | |
| 6 | 55-6572 | SCREW - alternator pivot (10 mm) | 1 | |
| 7 | 55-2769 | WASHER - special | 1 | |
| 8 | 55-421 | LOCKWASHER | 1 | |
| 9 | 55-5758 | SCREW - adjusting | 1 | |
| 10 | 99-8552 | ARM - alternator adjusting | 1 | |
| 11 | 55-5759 | BOLT - arm | 1 | |
| 12 | 55-5022 | SCREW - bracket | 2 | |
| 13 | 55-790 | LOCKWASHER | 2 | |
| 14 | 55-371 | FLATWASHER | 2 | |
| 15 | 91-3527 | BRACKET - alternator | 1 | |
| 16 | 55-371 | FLATWASHER | 2 | |
| 17 | 55-4621 | NUT | 1 | |
| 18 | 44-8235 | HARNESS - ground | 1 | |
| 19 | 55-7120 | NUT | 1 | |
| 20 | 55-6961 | SPACER | 1 | |
| 21 | 44-9041 | HARNESS | 1 | |
|
10-44-9041 | Проводка генератора | 6 920 ₽ |
|
