Установкa Thermo King Sentry 30 & 50 1000, 1200, 2000 w/C201 Engine схема REMOTE CONTROL BOX (50s) – 64A3
Обновление от: 3/20/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 99-6913 | BOX - remote control (only) | 1 | |
| 2 | 99-6914 | PANEL - unit control box | 1 | |
| 33-743 | GASKET - panel | 1 | ||
| 99-2026 | BRACKET - panel (connector) | 1 | ||
| 99-7495 | PLATE - grommet | 2 | ||
| 55-3027 | SCREW - bracket & plate | 4 | ||
| 55-4560 | NUT | 4 | ||
| 33-432 | GROMMET - harness | 1 | ||
| 3 | 55-2977 | SCREW - panel | 2 | |
| 55-3028 | WASHER - sealing | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 4 | 44-6238 | HARNESS - control box to remote box | 1 | |
| 44-5214 | SOCKET - switch panel in remote box | 1 | ||
| 44-5220 | COVER - connector | 1 | ||
| 44-5227 | PLUG - unit end panel | 1 | ||
|
10-44-5227 | Разъем, 12 контактов | 3 250 ₽ |
|
| 99-5316 | BRACKET - plug | 1 | ||
| 55-103 | SCREW - cover & bracket | 4 | ||
| 41-6310 | SOCKET - indicator light | 3 | ||
| 44-5654 | TERMINAL - bulb | 3 | ||
| 44-5030 | CONNECTOR (female pins, wire Nos. 7D, 29, 8, 7C, 26, CH) | 1 | ||
| 44-4925 | CONNECTOR (male pins, wire Nos. 7D, 7C) | 1 | ||
| 5 | 33-432 | GROMMET | 2 | |
| 6 | 99-7495 | PLATE - grommet | 2 | |
| 55-3027 | SCREW - plate | 4 | ||
| 55-4560 | NUT (hexstop) | 4 | ||
| 7 | 90-182 | LIGHT - indicator | 1 | |
| 55-1844 | SCREW - indicator light | 2 | ||
| 8 | 44-3035 | BULB - indicator light | 4 | |
| 9 | 33-749 | GROMMET (1/2 id) | 2 | |
| 10 | 45-252 | PANEL - switch | 1 | |
| 33-1541 | GASKET - donut | 1 | ||
| 11 | 55-5137 | NUT - captive | 2 | |
| 12 | 99-4526 | NAMEPLATE - TK | 1 | |
| 13 | 99-5635 | COVER - thermostat | 1 | |
| 33-1368 | GASKET - cover | 1 | ||
| 55-1512 | SCREW - cover | 4 | ||
| 14 | 45-1564 | THERMOSTAT | 1 | |
| 45-1565 | THERMOSTAT - TG IV (Thermoguard) | 1 | ||
| 44-5234 | SENSOR - thermostat | 1 | ||
|
10-44-5234 | Сенсор | 14 130 ₽ |
|
| 15 | 44-7171 | HARNESS (TG IV) | 1 | |
| 44-6317 | HARNESS (TG III) | 1 | ||
| 44-5310 | CONNECTOR - thermostat | 1 | ||
| 44-2825 | COVER - socket | 1 | ||
| 55-103 | SCREW - cover | 1 | ||
| 44-4925 | CONNECTOR - wire (Nos. CH, 8, 26, 29, 7C, 7D) | 1 | ||
| 44-5219 | CONNECTOR - electric (8 & CH) | 1 | ||
| 16 | 44-709 | SWITCH - diesel/electric | 1 | |
|
10-44-709 | Выключатель четырехполюсный | 5 130 ₽ |
|
| 17 | 99-2887 | NAMEPLATE - Diesel/Electric | 1 |
