Установкa Thermo King Sentry 30 & 50 1000, 1200, 2000 w/C201 Engine схема STOP/START ASSEMBLY (CYCLE SENTRY) – 60D6
Обновление от: 10/1/98
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 45-1184 | BRACKET & RELAY (Cycle Sentry) | 1 | ||
| 1 | 99-7286 | MARKSTRIP | 1 | |
| 2 | 99-7285 | BRACKET - relay | 1 | |
| 3 | 44-3184 | SOCKET - relay | 3 | |
| 44-6049 | RESISTOR - socket | 1 | ||
| 99-4605 | SPRING - holdown | 3 | ||
| 55-2270 | RIVET - spring & socket | 6 | ||
| 4 | 44-6048 | SWITCH - lockout | 1 | |
| 5 | 44-6046 | TIMER - solid state | 2 | |
| 99-6046 | PAD - relay retainer | 3 | ||
| 6 | 44-5537 | SOCKET - relay | 3 | |
| 55-3150 | SCREW - socket | 3 | ||
| 55-664 | NUT | 3 | ||
| 7 | 44-9391 | RELAY - mini | 3 | |
|
10-44-9391 | Реле | 3 250 ₽ |
|
| 8 | 44-6050 | RESISTOR | 1 | |
| 55-3845 | SCREW - resistor | 1 | ||
| 55-4337 | WASHER - insulating | 2 | ||
| 55-1516 | NUT | 1 | ||
| 9 | 55-3506 | SCREW - ground | 1 | |
| 55-401 | FLATWASHER | 1 | ||
| 55-1852 | LOCKWASHER | 2 | ||
| 55-346 | NUT | 2 | ||
| 10 | 44-5980 | BOARD - terminal | 1 | |
| 55-5699 | SCREW - terminal board | 2 | ||
| 55-686 | NUT | 2 | ||
| 44-5763 | DIODE - silicone rectifier | 3 | ||
| 11 | 44-6708 | HARNESS - thermostat (Cycle Sentry, w/o Fuelsaver) | 1 | |
| 12 | 44-5310 | CONNECTOR - thermostat | 1 | |
| 44-2825 | COVER - socket | 1 | ||
| 55-103 | SCREW - cover | 2 | ||
| 44-5763 | DIODE | 1 | ||
| 13 | 44-4925 | CONNECTOR (6-pin, wire Nos. 7C, 7D, 26, 29 CH, 8) | 1 | |
| 14 | 44-5030 | CONNECTOR (6-pin, wire Nos. 8, 7K, 7, 7A, 8TP) | 1 | |
| 15 | 44-6214 | HARNESS - auto start/stop/continuous run | 1 | |
| 16 | 44-709 | SWITCH - start/stop (off) | 1 | |
|
10-44-709 | Выключатель четырехполюсный | 5 130 ₽ |
|
| 17 | 44-5600 | CONNECTOR - main harness (6-pin, male) | 1 | |
| 18 | 44-5827 | CONNECTOR - switch panel (4-pin, male) | 1 | |
| 19 | 44-4925 | CONNECTOR (6-pin, male, TG) | 1 | |
| 20 | 41-6310 | SOCKET - indicator light | 1 | |
| 44-5654 | TERMINAL - bulb | 1 | ||
| 21 | 204-571 | TESTER - Cycle Sentry | 1 | |
| 22 | 204-637 | ADAPTER - Cycle Sentry | 1 |
