Установкa Thermo King SV-600 схема HOSE CONECTIONS – 268C2
Обновление от: 8/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR - QP16 XD (see 268B0) | 1 | |
| NSS | COMPRESSOR - TK21 XD (see 268C1) | 1 | ||
| 2 | 33-2882 | O-RING | 2 | |
| 3 | 22-992 | MANIFOLD - compressor | 1 | |
|
10-22-992 | Коллектор компрессора TM-15/16/21 | 1 950 ₽ |
|
| 55-5957 | SCREW - manifold | 1 | ||
| 55-7000 | LOCKWASHER | 1 | ||
| 4 | 33-1015 | O-RING (3/8 id) | A/R | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 33-566 | O-RING (1/2 id) | A/R | ||
| 33-672 | O-RING (9/16 id) | A/R | ||
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 33-2115 | O-RING (5/8 id) | A/R | ||
| 5 | 51-2406 | FITTING - 90 deg (tube-O, #8) | 1 | |
| 6 | 61-627 | HOSE (#8, 50 ft) | 1 | |
| 67-1709 | HOSE (#8, 300 ft) | 1 | ||
| 7 | 51-2441 | FITTING - straight (o-ring seal, #8 hose) | 1 | |
| 8 | 51-2488 | FITTING - 90 deg (o-ring seal, #12 hose x #10 fitting) | 1 | |
| 9 | 61-643 | HOSE (#12, 50 ft) | 1 | |
| 67-1711 | HOSE (#12, 300 ft) | 1 | ||
| 10 | 51-2503 | FITTING - straight (o-ring seal, #12 hose x #10 fitting) | 2 | |
| 11 | 51-2436 | FITTING - 90 deg (o-ring seal, #6 hose) | 4 | |
| 12 | 61-617 | HOSE (#6, 50 ft) | 1 | |
| 67-1708 | HOSE (#6, 300 ft) | 1 | ||
| 13 | 51-2457 | FITTING - 90 deg (tube-O, #12 hose x #10 fitting) | 1 |
