Установкa Thermo King SV-400 схема EVAPORATOR REFRIGERATION – 242B2
Обновление от: 1/11/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2489 | COIL - evaporator (KV-200) | 1 | |
| 67-2492 | COIL - evaporator (KV-300) | 1 | ||
| 2 | 61-5039 | TUBE - defrost | 1 | |
| 3 | 61-3193 | VALVE - expansion | 1 | |
| 4 | 61-5041 | TUBE - equalizer (KV-200) | 1 | |
| 61-5045 | TUBE - equalizer (KV-300) | 1 | ||
| 5 | 61-422 | FITTING - suction (w/nut) | 1 | |
| 6 | 55-9929 | NUT (ORS, #10) | 1 | |
| 7 | 33-2115 | O-RING - suction (5/8ID, #10) | 1 | |
| 8 | 33-1015 | O-RING - discharge & hot gas (3/8ID, #6) | 2 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 9 | 61-5040 | TUBE - discharge | 1 | |
| 61-434 | FITTING - discharge (w/nut, #6) | 1 | ||
| 10 | 61-3192 | VALVE - solenoid (defrost, 12V) | 1 | |
| 61-3387 | VALVE - solenoid (defrost, 24V) | 1 | ||
| 11 | 61-434 | FITTING - discharge (w/nut, #6) | 1 | |
| 12 | 55-9836 | NUT (ORS, #6) | 1 | |
| 13 | 33-547 | GROMMET (.375 id) | 1 |
