Установкa Thermo King SRT-III схема EVAPORATOR HEATING (1004) – 175D0
Обновление от: 4/24/03
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-1699 | PLATE & TUBE - assembly | 1 | |
| 55-8375 | NUT - captive | 5 | ||
| 55-7033 | FLATWASHER | 5 | ||
| 55-7404 | LOCKWASHER | 5 | ||
| 55-7340 | SCREW | 5 | ||
| 2 | 61-764 | TUBE - water | 1 | |
| 3 | 61-313 | TUBE & ADAPTER - water | 4 | |
| 4 | 61-769 | STRAINER - water | 1 | |
| 5 | 61-1702 | TUBE - water (SRT-III W) | 1 | |
| 61-1700 | TUBE - water (SRT-III N) | 1 | ||
| 6 | 67-1863 | COIL - evaporator/heater | 1 | |
| 92-2320 | INSULATION - coil | 2 | ||
| 7 | 91-8209 | FILTER - coil | 4 | |
| 8 | 33-452 | GROMMET | 2 | |
| 9 | 61-1701 | TUBE - heating | 1 | |
| 10 | 91-372 | CLAMP - tube | 1 | |
| 11 | 55-7027 | SCREW - clamp | 1 | |
| 12 | 55-7075 | FLATWASHER | 2 | |
| 13 | 55-7170 | LOCKWASHER | 1 | |
| 14 | 55-7354 | NUT | 1 | |
| 15 | 41-4151 | VALVE - solenoid (water, 24VDC) | 1 | |
| 60-271 | KIT - repair | 1 | ||
| 41-4201 | COIL (24V) | 1 | ||
| 16 | 61-1703 | TUBE - heating (SRT-III W) | 1 |
