Установкa Thermo King SR-70 Plus схема COMPRESSOR GROUP BITZER (701195) – 232G4
Обновление от: 3/1/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-861 | COMPRESSOR (see 226D1) | 1 | |
| 2 | 107-366 | CLUTCH - 2-B/2-A 24V | 1 | |
| 3 | 51-1998 | SCREW - clutch | 1 | |
| 4 | 77-2992 | PULLEY (2-B/2-A grooves, 7.87/8.82 in od) | 1 | |
| 5 | 45-2349 | FIELD - clutch (24V) | 1 | |
| 6 | 41-6795 | HARNESS - compressor | 1 | |
| 7 | 41-4147 | SWITCH - low pressure cutout | 1 | |
| 8 | 41-4146 | SWITCH - high pressure cutout | 1 | |
| 9 | 55-7755 | SCREW - clutch | 4 | |
| 10 | 55-790 | LOCKWASHER | 4 | |
| 11 | 55-895 | FLATWASHER | 4 |
