Установкa Thermo King SR-70 Plus схема HARNESS CONTROL PANEL TO ClimaAIRE I – 232G1
Обновление от: 1/27/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 41-8487 | HARNESS - control panel to ClimaAIRE I (1.5 M) | 1 | ||
| 41-4313 | HARNESS - control panel to ClimaAIRE I (12M) | 1 | ||
| 41-4512 | HARNESS - control panel to ClimaAIRE I (18 M) | 1 | ||
| 1 | 41-3856 | CONNECTOR - female (18-pin) | 1 | |
| 41-4247 | RECEPTACLE (.5 mm) | 8 | ||
| 41-4248 | RECEPTACLE (1.5 mm) | 1 | ||
| 2 | 41-5243 | TERMINAL - fingrip (16 - 14 ga) | 1 | |
| 3 | 41-661 | CONNECTOR - in-line (14-pin) | 1 | |
| 41-1807 | TERMINAL (18-24 ga) | 14 |
