Установкa Thermo King SR-70 Plus схема HARNESS CONTROL PANEL TO ClimaAIRE II – 232F0
Обновление от: 1/27/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 41-5378 | HARNESS - control panel to ClimaAIRE II (18M) | 1 | ||
| 1 | 41-3856 | CONNECTOR - female (18-pin) | 1 | |
| 41-4247 | RECEPTACLE (.5 mm) | 16 | ||
| 41-4248 | RECEPTACLE (1.5 mm) | 2 | ||
| 2 | 44-5838 | CONNECTOR - tower (2-pin) | 1 | |
| 44-5884 | TERMINAL - female (18-20 ga) | 1 | ||
| 44-8681 | SEAL - cable (red, 18-20 ga) | 1 | ||
| 44-5839 | TERMINAL - female (14-16 ga) | 1 | ||
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 1 | ||
| 3 | 44-6381 | CONNECTOR - female (1-pin) | 3 | |
| 44-5066 | TERMINAL - fingrip (14-18 ga) | 3 | ||
| 4 | 41-4949 | CONNECTOR - male (4-pin) | 1 | |
| 41-2779 | PIN - male | 3 | ||
| 5 | 41-2769 | TERMINAL - female (4-pin) | 1 | |
| 6 | 41-661 | CONNECTOR - in-line (14-pin) | 1 | |
| 41-1807 | TERMINAL (18-24 ga) | 22 | ||
| 7 | 41-650 | CONNECTOR - in-line (18-pin) | 1 |
