Установкa Thermo King SR-70 Plus схема SR-70 PLUS REFERENCE SHEET – 13U75

Обновление от: 6/8/12

Каталог запчастей для Thermo King SR-70 Plus SR-70 PLUS REFERENCE SHEET
№TK #ОписаниеКол-во
Цена
900895System - SR-70 100012/08
900896System - SR-70 100412/08
006131SR-70-100012/08
006132SR-70-100412/08
006905Refrigerant Circuiting Standard SR-7012/08
007023Electrical Circuiting - SR-70 Brushless 24VDC12/08
007439Reticulated Drain Pads12/08
099462Fresh Air Damper (Electric) 24V for SR units12/08
700107Refrigerant Hose Kit (Goodyear)12/08
700115SmartAIRE w/Harness 12M12/08
700127Water Valve Harness 10M12/08
700128Water Valve Harness 20M12/08
700129KIT WATER VALVE 2-WAY SERVOM12/08
700360SR-70 Cover12/08
700476Refrigerant Hose Kit (Goodyear)12/08
700477Refrigerant Hose Kit (Goodyear)12/08
700500Fittings12/08
700606Battery Cables12/08
700627Compressor X430-HPC TK High Torque Clutch12/08
700642Dehydrator12/08
700702Compressor Bitzer 4NFCY,24V12/08
700887Refrigerant Hose Kit (Goodyear)12/08
700888Refrigerant Hose Kit (Goodyear)12/08
700889Harness - ClimaAIRE (Unit to Compressor - 12 M)12/08
700891Alternator Accessories12/08
700910Tube Connection12/08
700923Air Filter12/08
700421SmartAIRE w/Harness 18.3M12/08
701039ClimaAIRE I DP w/ Harness (Unit to Driver Panel - 12 m length)12/08
701132Compressor Bitzer F400Y12/08
701138Shuhang Fans & Blowers12/08
701139Refrigerant Hose Kit (Goodyear)12/08
701192Compressor X430-HPC 24V TK 2B/2A12/08
701195Compressor Bitzer 4NFCY,24V12/08
701551Harness - ClimaAIRE (Unit to Compressor - 13M)12/08
701552Pump Harness 11M12/08
701553Pump Harness 14M12/08
701557Installation Kit12/08
701577Refrigerant Hose Kit #12,#16. 1M (Fefristar)12/08
701578Refrigerant Hose Kit #16,#20, 1M (Fefristar)12/08
715247Muffler Kit12/08
701633Harness - ClimaAIRE (Unit to Compressor - 18)12/08
718377Compressor Kit - TM31, 24V, 2B Pulley, POE Oil12/08
718379Kit - Oil, POE (8 oz (0.24 Liter) Can for TM and A6 Compressor)12/08
719005Boost Pump12/08
719007Harness Water Pump 9M12/08
719135ClimaAIRE II DP with Display w/ Harness (Unit to Driver Panel - 18.3 m length) Recommended12/08
719300ClimaAIRE I DP w/ Harness (Unit to Driver Panel - 12 m length)12/08
719301Harness - ClimaAIRE (Unit to Compressor - 12 m length) Recommended12/08
719305Alternator Kit - 150A, 24VDC, 24V Excitation, 3.25 in for ClimaAIRE12/08
719802Fittings12/08
720171Muffler Kit12/08
720202Electrical Circuiting - SR-70 1000/1004 for ClimaAIRE I12/08
720203Electrical Circuiting - SR-70 1000/1004 for ClimaAIRE II w/ Display12/08
720209Refrigerant Fittings Kit for X430 Comp - Side (S 45 deg/ D 45 deg) Recommended12/08
720242Refrigerant Hose Kit - Mix (#16/#20, 1 m w/o Fittings) Recommended12/08
720366Refrigerant Fittings Kit (#20/#16 - S 90 deg/D 45 deg) Recommended12/08
720369Refrigerant Fittings Kit - TM31 Comp Side (S 45 deg/D 45 deg) Recommended12/08
720376Refrigerant Fittings Kit - Unit Side (S 90 deg/D 45 deg) Recommended12/08
720377Refrigerant Fittings Kit - Unit Side (S 45 deg/D 90 deg)12/08
720385Refrigerant Hose Kit - Mix (#12/#16, 1 m w/o Fittings) Recommended12/08
720395Fittings Kit for Tube Installation12/08
720587Compressor X430-HPC, R134a, 24V, 2B/2A Pulley, 8.03 in/8.89 in12/08
720760Harness (A/C Unit to TM Compressor - 14 m length)12/08
720761Harness (A/C Unit to TM Compressor - 12 m length)12/08
800226Installation Kit12/08
880099Installation Kit - SR-70 16 m Drain Hose12/08
880110Kit - Adapters for X430 Compressor12/08
