Установкa Thermo King SR-50S W Split 1000/1004 схема FRAME & INSULATION – 181G5
Обновление от: 11/6/02
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-6545 | BASE - condenser | 1 | |
| 55-7866 | NUT - captive (M4) | 1 | ||
| 55-7373 | NUT - captive (M6) | 2 | ||
| 2 | 92-2575 | PLUG - front box | 1 | |
| 3 | 98-6546 | BASE - evaporator | 1 | |
| 55-7866 | NUT - captive (M4) | 22 | ||
| 55-7373 | NUT - captive (M6) | 28 | ||
| 55-9814 | NUT - captive (M6) | 2 | ||
| 55-7012 | NUT - captive (M6) | 8 | ||
| 4 | 33-3452 | INSULATION - duct (front right) | 1 | |
| 5 | 33-3457 | INSULATION - duct (side, left) | 1 | |
| 6 | 33-3458 | INSULATION - duct (side, right) | 1 | |
| 7 | 33-3459 | INSULATION - front | 1 | |
| 8 | 33-3454 | INSULATION - duct (back right, 1000 only) | 1 | |
| 33-3453 | INSULATION - duct (back right, 1004 only) | 1 | ||
| 9 | 33-3464 | INSULATION - evaporator | 2 | |
| 10 | 33-3465 | INSULATION - duct | 4 | |
| 11 | 33-3466 | INSULATION - duct (right) | 1 | |
| 12 | 33-3709 | INSULATION - duct (back, left) | 1 | |
| 13 | 33-3710 | INSULATION - duct (front left) | 1 | |
| 14 | 33-3711 | INSULATION - back | 1 | |
| 15 | 33-3468 | INSULATION - long | 2 | |
| 16 | 33-3651 | INSULATION - evaporator (front left) | 1 | |
| 17 | 33-3652 | INSULATION - evaporator | 2 | |
| 18 | 33-3653 | INSULATION - evaporator (back right) | 1 | |
| 19 | 92-1456 | PLUG (1000 only) | 1 | |
| 20 | 33-3654 | INSULATION | 2 | |
| 21 | 33-549 | GROMMET | 4 | |
| 22 | 33-415 | GROMMET | 1 |
