Установкa Thermo King SR-50S 1000 & 1004 схема CONTROL PANEL for ClimaAIRE I (12V) – 164A9
Обновление от: 3/4/03
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-9344 | FUSE - boost pump (15 amp) | 1 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 2 | 41-1292 | FUSE - compressor clutch (5 amp) | 1 | |
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 3 | 41-2978 | FUSE - evaporator blower (20 amp) | 4 | |
| 30-41-2978 | Предохранитель 32V 20А | 500 ₽ |
|
|
| 4 | 41-1259 | FUSE - condenser fan (25 amp) | 2 | |
|
10-41-1259 | Предохранитель 25 ампер 10 шт | 1 860 ₽ |
|
| 5 | 41-1932 | FUSE - damper motor (1 amp) | 1 | |
| 6 | 55-7034 | NUT | 7 | |
| 7 | 99-3427 | MOUNT - cable tie | A/R | |
| 55-5130 | RIVET - mount | A/R | ||
| 55-2332 | BANDWRAP (0.75 dia, black) | A/R | ||
| 55-2330 | BANDWRAP (1.75 dia, black) | A/R | ||
| 8 | 41-895 | RELAY | 13 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 9 | 41-4157 | SENSOR - temperature | 1 | |
| 10 | 92-1462 | BRACKET - control panel | 1 | |
| 92-1506 | STRIP - edge protection | 2 | ||
| 11 | 41-4154 | BOARD - pc | 1 | |
| 12 | 92-1463 | NAMEPLATE - 12VDC | 1 | |
| 13 | 55-9623 | STUD - pc board | 7 | |
| 14 | 55-9624 | SPACER - pc board | 7 |
