Установкa Thermo King SR-50C 1000 & 1004 схема CONTROL PANEL - 12V – 265F1
Обновление от: 4/17/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-5542 | PANEL - control | 1 | |
| 2 | 41-4157 | SENSOR - temperature | 1 | |
| 3 | 99-3427 | MOUNT - bandwrap | 2 | |
| 55-5130 | RIVET - mount | 2 | ||
| 4 | 55-2332 | BANDWRAP | 2 | |
| 5 | 92-5543 | NAMEPLATE - SR-50C 12V | 1 | |
| 6 | 41-1932 | FUSE (1 amp, 32 V) | 1 | |
| 7 | 41-1292 | FUSE (5 amp, 32 V) | 1 | |
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 8 | 44-9344 | FUSE (15 amp, 32 V) | 1 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 9 | 41-1259 | FUSE (25 amp, 32 V) | 4 | |
|
10-41-1259 | Предохранитель 25 ампер 10 шт | 1 860 ₽ |
|
| 10 | 41-4154 | BOARD - pc | 1 | |
| 11 | 51-310 | NUT - acorn (plastic) | 1 | |
| 12 | 55-9623 | STUD - self clinching | 8 | |
| 13 | 55-9624 | SPACER | 8 | |
| 14 | 55-7034 | LOCKNUT | 7 | |
| 15 | 41-895 | RELAY | 11 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 16 | 41-4340 | RESISTOR | 2 | |
| 51-1473 | STUD - self-clinching (M5) | 4 | ||
| 55-7089 | FLATWASHER | 4 | ||
| 55-7034 | LOCKNUT | 4 | ||
| 17 | NSS | TERMINAL - minus (see 265F4) | 1 | |
| 18 | NSS | TERMINAL - plus (see 265F3) | 1 | |
| 19 | 92-3279 | RUBBER - profile | A/R | |
| 20 | 91-7509 | NAMEPLATE - Positive/Negative | 1 |
