Установкa Thermo King SR-50C 1000 & 1004 схема COMPRESSOR GROUP TM16 XD – 263G5
Обновление от: 5/2/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-570 | COMPRESSOR TM16 XD | 1 | |
| 102-875 | COMPRESSOR - TM16 XD (less clutch) | 1 | ||
| 107-241 | CLUTCH (12V, 2A groove) | 1 | ||
|
10-107-241 | Сцепление/муфта электромагнитная, 2A/12V | 6 470 ₽ |
|
| 22-1263 | FILTER - suction | 1 | ||
| 102-571 | COMPRESSOR TM16 XD | 1 | ||
| 102-875 | COMPRESSOR - TM16 XD (less clutch) | 1 | ||
| 107-324 | CLUTCH (24V, 2A groove) | 1 | ||
| 22-1263 | FILTER - suction | 1 | ||
| 102-807 | COMPRESSOR TM16 XD | 1 | ||
| 102-875 | COMPRESSOR - TM16 XD (less clutch) | 1 | ||
| 107-311 | CLUTCH (12V, 8V poly groove) | 1 | ||
|
10-107-261 | Муфта электромагнитная, 8PV/12V, TM13/15/16, QP13/15/16 | 7 740 ₽ |
|
| 22-1263 | FILTER - suction | 1 | ||
| 102-668 | COMPRESSOR TM16 XD | 1 | ||
| 18-10158-04 OEM | Компрессор, TM-16, 24V 8PV, R134A/R404A | 22 740 ₽ |
|
|
|
10-TM-16-8-24 | Компрессор, TM-16, 24V 8PV, R134A/R404A | 22 740 ₽ |
|
| 102-875 | COMPRESSOR - TM16 XD (less clutch) | 1 | ||
| 107-262 | CLUTCH (24V, 8V poly groove) | 1 | ||
|
10-107-262 | Муфта электромагнитная, 8PV/24V, TM13/15/16, QP13/15/16 | 7 740 ₽ |
|
| 22-1263 | FILTER - suction | 1 | ||
| 203-427 | OIL - compressor (solest 120) | A/R | ||
| 2 | 44-7327 | CONNECTOR - tower (1 pin) | 1 | |
| 44-5884 | TERMINAL (18-20 gauge, female) | 1 | ||
| 44-8681 | SEAL (red, 0.051 - 0.067 id) | 1 | ||
| 3 | 91-7520 | NAMEPLATE - 12VDC | 1 | |
| 4 | 91-7543 | NAMEPLATE - 24VDC | 1 |
