Установкa Thermo King SR-500 схема CONTROL PANEL (24V) – 216D5
Обновление от: 9/25/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-6000 | BRACKET - control panel | 1 | |
| 55-7172 | SCREW - bracket | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 51-290 | NUT - captive | 4 | ||
| 2 | 41-4154 | PANEL - control, pcb | 1 | |
| 3 | 55-9623 | STUD - panel | 8 | |
| 4 | 55-9624 | SPACER | 8 | |
| 5 | 55-7034 | NUT | 7 | |
| 6 | 51-310 | NUT - plastic | 1 | |
| 7 | 41-896 | RELAY - mini | 13 | |
| 8 | 41-1932 | FUSE (1 amp) | 1 | |
| 9 | 41-1292 | FUSE (5 amp) | 1 | |
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 10 | 44-9344 | FUSE (15 amp) | 5 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 11 | 41-2978 | FUSE (20 amp) | 2 | |
| 30-41-2978 | Предохранитель 32V 20А | 500 ₽ |
|
|
| 12 | 33-1055 | GROMMET (0.375 id) | 1 | |
| 13 | 92-3279 | STRIP - flange | A/R | |
| 14 | 92-2978 | NAMEPLATE - Control Panel | 1 |
