Установкa Thermo King SR-10F схема COVER & FAN & INSULATION – 229C4
Обновление от: 3/24/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-3586 | COVER - plastic | 1 | |
| 55-8837 | SCREW - cover | 6 | ||
| 51-871 | WASHER | 6 | ||
| 2 | 78-1414 | FAN - assembly (24 V) | 1 | |
| 78-1493 | FAN - assembly (12 V) | 1 | ||
| 3 | 78-1416 | GUARD - fan | 1 | |
| 4 | 78-1414 | FAN (24 V) | 1 | |
| 78-1494 | FAN (12 V) | 1 | ||
| 51-1243 | SCREW | 1 | ||
| 55-7372 | SCREW - fan | 4 | ||
| 51-130 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 55-7042 | NUT | 4 | ||
| 5 | 99-4931 | NAMEPLATE - arrow | 1 | |
| 6 | 91-7551 | NAMEPLATE - TK Logo | 2 | |
| 7 | 92-1307 | NAMEPLATE - IR Logo | 2 | |
| 8 | 99-8506 | NAMEPLATE - Caution, Fan | 1 | |
| 9 | 99-8507 | NAMEPLATE - Caution, Fan | 1 | |
| 10 | 92-3587 | INSULATION - cover | 1 |
