Установкa Thermo King SR-10F схема CONTROL PANEL FOR CA I D (12 V) – 229A0
Обновление от: 9/4/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-6973 | BRACKET - control panel | 1 | |
| 55-5130 | RIVET - bracket | 3 | ||
| 2 | 44-5537 | SOCKET - relay | 6 | |
| 55-2260 | RIVET - socket | 3 | ||
| 3 | 41-895 | RELAY | 6 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 4 | 41-4340 | RESISTOR | 1 | |
| 55-7340 | SCREW - resistor | 2 | ||
| 55-7089 | FLATWASHER | 2 | ||
| 55-8375 | NUT - captive | 2 | ||
| 5 | 41-4965 | HOLDER - fuse | 3 | |
| 6 | 41-1292 | FUSE (5 amp) | 1 | |
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 7 | 44-9344 | FUSE (15 amp) | 1 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 8 | 41-1259 | FUSE (25 amp) | 1 | |
|
10-41-1259 | Предохранитель 25 ампер 10 шт | 1 860 ₽ |
|
| 9 | 55-9367 | STUD - ground (M8) | 1 | |
| 55-8693 | WASHER (nylon) | 1 | ||
| 55-8631 | WASHER (nylon w/ shoulder) | 1 | ||
| 55-448 | FLATWASHER | 2 | ||
| 55-8955 | FLATWASHER | 4 | ||
| 55-3238 | LOCKWASHER | 3 | ||
| 305-1653 | NUT | 4 | ||
| 10 | 55-9191 | STUD - ground (M10) | 1 | |
| 55-3672 | LOCKWASHER | 1 | ||
| 55-448 | FLATWASHER | 4 | ||
| 55-3066 | LOCKWASHER | 2 | ||
| 55-9189 | NUT | 4 | ||
| 11 | 41-4157 | SENSOR - temperature | 1 | |
| 12 | 51-1631 | STRAP - cable | 4 | |
| 13 | 33-612 | GROMMET (0.875 id) | 1 | |
| 14 | 92-6974 | NAMEPLATE - fuses (12 V) | 1 | |
| 15 | 91-7509 | NAMEPLATE - positive/negative | 1 |
