Установкa Thermo King SPECTRUM TS w/TK 376 Engine схема ALTERNATOR ASSEMBLY (90 AMP - PRESTOLITE) – 217G1
Обновление от: 8/3/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 41-2705 | ALTERNATOR | 1 | ||
| 10-45-1706 | Генератор 90A, URD | 43 600 ₽ |
|
|
|
10-41-2705 | Генератор, 90А (RD-II, SPECTRUM TS-500 376) | 16 190 ₽ |
|
| 1 | 55-8695 | NUT - pulley | 1 | |
| 2 | 55-8696 | LOCKWASHER | 1 | |
| 3 | 41-2487 | FAN | 1 | |
| 4 | 41-1729 | SPACER | 1 | |
| 5 | 41-2334 | HOUSING - front | 1 | |
| 6 | 77-2488 | BEARING - front | 1 | |
| 7 | 77-2399 | RETAINER - front bearing | 1 | |
| 8 | 41-1731 | ROTOR - assembly | 1 | |
| 9 | 77-2489 | BEARING - ring | 1 | |
| 10 | 41-1732 | SLIP RING | 1 | |
| 11 | 41-7427 | STATOR - assembly | 1 | |
| 12 | 41-7428 | RECTIFIER - positive | 1 | |
| 13 | 41-7425 | RECTIFIER - negative | 1 | |
| 14 | 41-1736 | WASHER - insulating | 2 | |
| 15 | 51-1581 | WASHER - insulating | 1 | |
| 16 | 77-1062 | O-RING | 1 | |
| 17 | 41-1737 | HOUSING - rear | 1 | |
| 18 | 55-8698 | SLEEVE | 2 | |
| 19 | 55-8699 | SLEEVE | 1 | |
| 20 | 51-1582 | WASHER - insulating | 1 | |
| 21 | 51-636 | FLATWASHER | 2 | |
| 22 | 55-8702 | FLATWASHER | 1 | |
| 23 | 55-9702 | NUT | 5 | |
| 24 | 41-1738 | CAPACITOR | 1 | |
| 25 | 55-8703 | NUT | 2 | |
| 26 | 41-1739 | BRUSH | 1 | |
|
10-41-1739 | Щетки генератора, KD/MD/RD/TD-II / TS/URD / SB-II/III | 1 590 ₽ |
|
| PP-41-1739 | Щетки генератора, KD/MD/RD/TD-II / TS/URD / SB-II/III | 510 ₽ |
|
|
| 27 | 55-8704 | SCREW - brush | 2 | |
| 28 | 33-2851 | GASKET - regulator | 1 | |
| 29 | 41-1740 | REGULATOR | 1 | |
|
10-41-1740 | Реле-регулятор, KD/MD/RD/TD-II / TS/URD / SB-II/III | 4 600 ₽ |
|
| 30 | 55-8705 | SCREW | 2 | |
| 31 | 55-8984 | SCREW - thru | 4 |
