Установкa Thermo King SLX 200 Complete схема REAR VIEW THERMOMETER, TEMP WATCH – 192E5
Обновление от: 4/20/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 40-916 | THERMOMETER - forward view (Temp Watch, 15 ft sensor harness) | 1 | |
| 40-917 | THERMOMETER - rear view (15 ft sensor harness) | 1 | ||
| 40-918 | THERMOMETER - rear view (60 ft sensor harness) | 1 | ||
| 2 | 91-8733 | BRACKET - remote light | 1 | |
| 3 | 91-9274 | SUN VISOR | 1 | |
| 55-5640 | SCREW - sheet metal (#10) | 11 | ||
| 55-2001 | FLATWASHER | 16 | ||
| 55-5294 | CLAMP - harness | 5 | ||
| 55-2330 | BANDWRAP | A/R | ||
| 4 | 40-1119 | KIT - temperature display (left side, degrees F) | 1 | |
| 40-1120 | KIT - temperature display (left side, degrees C) | 1 | ||
| 5 | 40-1121 | KIT - temperature display (right side, UK, degrees C) | 1 | |
| 6 | NSS | DISPLAY | 1 | |
| 7 | 55-5294 | CLAMP - harness | 5 | |
| 51-321 | RIVET | 5 |
