Установкa Thermo King SLR65 схема REFRIGERATION EVAPORATOR (1004) – 251D5
Обновление от: 3/23/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-5365 | TUBE - liquid assembly | 1 | |
| 55-3247 | BUSHING | 1 | ||
| 55-6837 | SHOULDER | 1 | ||
| 55-6838 | NUT | 1 | ||
| 51-1545 | FITTING | 1 | ||
| 2 | 61-5212 | DEHYDRATOR w/sightglass | 1 | |
| 3 | 33-566 | O-RING (.50 id) | 2 | |
| 4 | 61-5366 | TUBE - expansion valve assembly | 1 | |
| 61-863 | VALVE - expansion | 1 | ||
| 5 | 33-2846 | O-RING (7/16 id) | 2 | |
| 6 | 67-2642 | COIL - evaporator w/heat (rear) | 1 | |
| 7 | 67-2641 | COIL - evaporator w/heat (front) | 1 | |
| 55-1587 | SCREW - coil | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 55-4414 | WASHER (.281 id) | 8 | ||
| 8 | 61-5367 | TUBE - suction assembly | 1 | |
| 9 | 33-2848 | O-RING (9/16 id) | 2 | |
| 10 | 61-5368 | TUBE - discharge assembly | 1 | |
| 51-2090 | NUT - bulkhead | 1 | ||
| 11 | 33-1809 | GROMMET (.50 id) | 1 | |
| 12 | 41-9634 | SWITCH - lpco | 1 | |
| 13 | 41-9635 | SWITCH - hpco | 1 | |
| 14 | 92-8721 | BRACKET - tube support | 1 | |
| 15 | 55-6225 | CLAMP - dehydrator | 1 | |
| 16 | 51-2038 | MOUNT | 2 | |
| 55-2977 | SCREW - mount | 2 | ||
| 17 | 41-6844 | THERMOSTAT - freeze | 1 | |
| 55-3027 | SCREW - stat | 2 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 18 | 91-1800 | CLAMP - tube (2 x .50 id) | 2 | |
| 19 | 55-6389 | CLAMP - tube (.50 id) | 1 | |
| 20 | 55-6388 | CLAMP - tube (.375 id) | 1 | |
| 55-1587 | SCREW - clamp (.75 in long) | 2 | ||
| 55-2979 | SCREW - clamp (1.25 in long) | 1 | ||
| 55-3121 | SCREW - clamp (1.50 in long) | 1 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 |
