Установкa Thermo King SL-400 схема BELT GROUP (30s) – 149B10
Обновление от: 3/30/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 77-2132 | PULLEY - fanshaft | 1 | |
| 77-2605 | PULLEY - fanshaft (SL-400) | 1 | ||
| 55-6479 | SCREW - pulley | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 55-7069 | FLATWASHER | 2 | ||
| 55-457 | KEY | 1 | ||
| 2 | 78-978 | BELT - idler to fanshaft | 1 | |
|
10-78-978 | Ремень вентиляторов, SL | 3 930 ₽ |
|
|
PP-78-978 | Ремень вентиляторов, SL | 2 080 ₽ |
|
| 77-983 | BELT - idler to fanshaft (SL-400) | 1 | ||
| 3 | 77-2043 | PULLEY - idler (see 100B11) | 1 | |
| 91-4833 | PLATE - idler | 1 | ||
| 55-7571 | SCREW - plate | 1 | ||
| 55-5914 | FLATWASHER | 1 | ||
| 55-7569 | WASHER - special | 1 | ||
| 55-7570 | WASHER - special | 1 | ||
| 55-7003 | LOCKNUT | 1 | ||
| 4 | 77-2134 | PULLEY - jackshaft to fanshaft | 1 | |
| 55-457 | KEY | 2 | ||
| 55-6479 | SCREW - pulley | 4 | ||
| 55-790 | LOCKWASHER | 4 | ||
| 5 | 77-2144 | PULLEY - alternator (see 111E13) | 1 | |
| 6 | 78-679 | BELT - alternator | 1 | |
| 10-78-679 | Ремень генератора и водяной помпы, SL/SMX 30 / MD-II/KD-II | 1 880 ₽ |
|
|
|
PP-78-679 | Ремень генератора и водяной помпы, SL/SMX 30 / MD-II/KD-II | 1 120 ₽ |
|
| 7 | 91-4831 | ANGLE - jackshaft | 1 | |
| 55-4723 | SCREW - angle | 2 | ||
| 55-5006 | LOCKWASHER | 2 | ||
| 55-2769 | FLATWASHER | 2 | ||
| 91-4832 | NUTPLATE | 2 | ||
| 8 | 78-830 | JACKSHAFT (see 100F11) | 1 | |
| 55-8971 | SCREW - jackshaft | 2 | ||
| 55-7069 | FLATWASHER | 1 | ||
| 55-2292 | WASHER - special | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 55-7006 | NUT | 2 | ||
| 9 | 91-4834 | ARM - adjusting | 1 | |
| 55-6215 | SCREW - arm | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 55-7069 | FLATWASHER | 2 | ||
| 55-2769 | WASHER - special | 2 | ||
| 55-7006 | NUT | 2 | ||
| 10 | 77-2206 | PULLEY - engine to jackshaft | 1 | |
| 11 | 78-1089 | BELT - engine to jackshaft | 1 | |
| 10-78-1089 | Ремень двигатель - промвал, SL 30 | 7 100 ₽ |
|
|
|
PP-78-1089 | Ремень двигатель - промвал, SL 30 | 2 870 ₽ |
|
| 78-1085 | BELT - engine to jackshaft (SL-400) | 1 | ||
| 10-78-1085 | Ремень двигатель - промвал, SL-400 30 | 6 170 ₽ |
|
|
| PP-78-1085 | Ремень двигатель - промвал, SL-400 30 | 3 200 ₽ |
|
|
| 12 | 77-2525 | PULLEY - idler (3/99 & after, see 152A14) | 2 | |
| 77-2525 OEM | Шкив, SL | 27 770 ₽ |
|
|
| 77-2512 | PULLEY - idler (before 3/99, see 148B14) | 1 | ||
| 77-2526 | SPACER - tensioner | 1 | ||
| 13 | 91-8965 | BRACKET - tensioner (before 3/99, see 148B14) | 1 | |
| 91-9349 | BRACKET - tensioner (3/99 & after, see 152A14) | 1 | ||
| 14 | 91-8922 | GUARD - belt (before 3/99, see 148B14) | 1 | |
| 91-9306 | GUARD - belt (3/99 & after, see 152A14) | 1 | ||
| 15 | 77-2520 | PULLEY - fan drive (6.77 od, high capacity) | 1 | |
| 77-2388 | PULLEY - fan drive (7.5 od) | 1 | ||
| 55-8472 | SCREW - pulley | 4 | ||
| 55-1173 | LOCKWASHER | 4 | ||
| 16 | 11-8902 | SPACER - pulley | 1 | |
| 17 | 11-9451 | PUMP - water (ELC compatible, see 142F7) | 1 | |
| 77-1346 | SPACER - pulley | 1 | ||
| 55-144 | SCREW | 3 | ||
| 55-371 | FLATWASHER | 3 | ||
| 55-421 | LOCKWASHER (internal) | 3 | ||
| 18 | 78-1340 | BELT - water pump | 1 | |
|
20-78-1968 | Ремень водяного насоса, SL/SLe/SLX/SLXe | 5 210 ₽ |
|
| 10-78-1340 | Ремень водяного насоса, SL/SLe/SLX/SLXe | 3 460 ₽ |
|
|
|
PP-78-1340 | Ремень водяного насоса, SL/SLe/SLX/SLXe | 890 ₽ |
|
| 19 | 70-212 | PULLEY - crankshaft (see 145F7) | 1 |
