Установкa Thermo King SGSM 3000 схема ALTERNATOR GROUP – 222D1
Обновление от: 5/6/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 404-153 | ALTERNATOR | 1 | |
| 2 | 55-3985 | STUD - housing | 4 | |
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2640 | NUT | 4 | ||
| 3 | 11-9482 | DISC - flex | 1 | |
| 4 | 77-2747 | BEARING | 1 | |
| 5 | 44-4678 | RECTIFIER - positive | 1 | |
| 6 | 44-4679 | RECTIFIER - negative | 1 | |
| 55-664 | NUT - rectifier | 6 | ||
| 55-2964 | LOCKWASHER | 6 | ||
| 55-2001 | FLATWASHER | 6 | ||
| 7 | 55-9820 | SPACER - fan | 6 | |
| 8 | 77-2654 | BLOWER | 1 | |
| 9 | 55-8137 | SCREW - fan | 6 | |
| 55-7066 | LOCKWASHER | 7 | ||
| 55-6988 | FLATWASHER | 6 | ||
| 10 | 45-2301 | EXCITER - stator (14 ohm) | 1 | |
| 11 | 55-9497 | PIN - dowel | 2 | |
| 12 | 55-8137 | SCREW - disc to flywheel | 6 | |
| 55-7066 | LOCKWASHER | 6 | ||
| 55-6988 | FLATWASHER | 6 | ||
| 13 | 55-3539 | CONNECTOR - barb | 1 | |
| 33-1056 | O-RING | 1 | ||
| 55-2636 | NUT | 1 | ||
| 14 | 98-5035 | HOSE - harness (cut to 26.0 inches) | A/R | |
| 15 | 91-3439 | COVER - harness | 1 | |
| 16 | 33-1420 | GASKET - cover | 1 | |
| 17 | 55-1587 | SCREW - cover | 2 | |
| 55-2086 | FLATWASHER | 2 | ||
| 55-1800 | LOCKWASHER | 2 |
