Установкa Thermo King SB-III SR MP IV w/di 2.2 Engine схема HARNESS GROUP (SB-III MP IV) – 104E10
Обновление от: 11/27/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-1168 | HARNESS - main | 1 | |
| 2 | 44-9585 | PLUG (2-pin, female) | 5 | |
| 3 | 44-9586 | WEDGE (2 terminal plug) | 5 | |
| 4 | 44-9587 | TERMINAL (16 gauge, female) | 10 | |
| 5 | 44-8858 | CONNECTOR - relay board (18-pin) | 1 | |
| 6 | 44-9240 | TERMINAL - female (16-20 ga) | 18 | |
| 7 | 44-5814 | CONNECTOR - relay board (4-pin, female) | 1 | |
| 8 | 44-5630 | TERMINAL (14-16 gauge, female) | 3 | |
| 44-9542 | TERMINAL (10 gauge, female) | 3 | ||
| 9 | 44-5219 | CONNECTOR - relay board (2-pin, female) | 1 | |
| 10 | 44-5942 | TERMINAL (2, 14-16 gauge, female) | 2 | |
| 11 | 44-5600 | CONNECTOR - circuit breaker (6-pin, female) | 1 | |
| 12 | 44-5139 | TERMINAL - fingrip (14-16 gauge) | 5 | |
| 44-9543 | TERMINAL (10 gauge, male) | 1 | ||
| 13 | 44-5219 | CONNECTOR - remote light (2-pin, female) | 1 | |
| 14 | 44-5719 | CONNECTOR - remote light (8-pin, female) | 1 | |
| 15 | 44-5631 | TERMINAL (female) | 1 | |
| 16 | 44-9589 | RECEPTACLE (2-pin, male) | 5 | |
| 17 | 44-9590 | WEDGE - terminal | 5 | |
| 18 | 44-9591 | TERMINAL - pin (16-18 ga) | 10 |
