Установкa Thermo King SB-III SR MP IV+ TG VI & Rail w/se 2.2 Engine схема SB-III SR MP IV+ TG VI & Rail w/se 2.2 ENGINE REFERENCE SHEET – 2U90
Обновление от: 9/10/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 913515 | System - SB-III 30 SR | 2/95 | ||
| 914561 | System - SB-III 30 SR | 2/95 | ||
| 914568 | System - SB-III 30 MAX+ | 2/95 | ||
| 915077 | System - SB-III 30 TF+ | 2/95 | ||
| 915285 | System - SB-III 50 MAX+ 230V | 2/95 | ||
| 915782 | System - SB-III Rail 30 SR+ | 9/10 | ||
| 048333 | SB-III SR MP IV | 2/95 | ||
| 048444 | SB-III SR MP IV+ | 2/95 | ||
| 048542 | SB-III 30 MAX TG VI | 8/95 | ||
| 048543 | SB-III 30 MAX TF | 8/95 | ||
| 048569 | SB-III MAX+ TG VI | 3/97 | ||
| 048650 | SB-III Rail 30 SR+ | 12/97 | ||
| 048655 | SB-III 50 SR+ | 10/98 | ||
| 048024 | Top Screen | 2/95 | ||
| 048030 | Condenser Shutters | 2/95 | ||
| 048152 | Painted Grille | 2/95 | ||
| 048233 | Fresh Air Exchange | 2/95 | ||
| 048332 | Compound Gauge | 2/95 | ||
| 048355 | Threaded Battery Cables | 2/95 | ||
| 048387 | Datalogger/Communications | 2/95 | ||
| 048407 | Oil Bath Air Cleaner | 2/95 | ||
| 048408 | Silicone Hose | 2/95 | ||
| 048411 | Modulation | 2/95 | ||
| 048413 | 65 Amp Alternator | 2/95 | ||
| 048414 | Compressor Oil Filter | 2/95 | ||
| 048416 | Fuel Heater w/ Silicone Hoses | 2/95 | ||
| 048434 | R403B | 2/95 | ||
| 048443 | Oil Bath Air Cleaner - 50s | 3/97 | ||
| 048469 | R404A | 2/95 | ||
| 048476 | Bulkhead | 3/96 | ||
| 048482 | ABS Doors | 2/95 | ||
| 048483 | ABS Doors - SB-III 50 | 3/97 | ||
| 048489 | External Battery Box | 2/95 | ||
| 048495 | LdB | 2/95 | ||
| 048502 | Fuel Heater | 2/95 | ||
| 048503 | Silicone Hose | 2/95 | ||
| 048505 | Datalogger Communication - SB-III SR | 2/95 | ||
| 048508 | LdB - SB-III 50 | 3/97 | ||
| 048509 | Modulation - SB-III MP IV+ | 2/95 | ||
| 048514 | LdB/ABS Doors - SB-III 30 SR | 2/95 | ||
| 048515 | 65 Amp Alternator | 2/95 | ||
| 048534 | Fuel Heater - Silicone Hoses | 3/97 | ||
| 048541 | Door Switch - SB-IIIS SR | 2/95 | ||
| 048544 | SB-III 30 MAX TG VI C/S | 2/95 | ||
| 048548 | SB-III Crate - Wood | 2/95 | ||
| 048558 | Fresh Air Exchange w/ LdB | 9/97 | ||
| 048561 | SB-III 30 R134a | 2/95 | ||
| 048570 | SB-III 50 R134a | 3/97 | ||
| 048601 | Fuel Tank - 30 Gallon 22 Inch Dia Aluminum | 2/95 | ||
| 048602 | Fuel Tank - 50 Gallon 22 Inch Dia Aluminum | 2/95 | ||
| 048603 | Fuel Tank Kit - 50 Gallon 22 Inch Dia Aluminum | 9/10 | ||
| 048604 | Fuel Tank - 110 Gallon 22 Inch Diameter Steel | 2/95 | ||
| 048605 | Door Switch - SB-III | 12/97 | ||
| 048612 | SB-III S-UK | 3/97 | ||
| 048620 | SB-III 50 230V Phase Correction | 3/97 | ||
| 048621 | SB-III 50 230V Phase Correction C/S | 3/97 | ||
| 048622 | SB-III 50 460V Phase Indicator | 3/97 | ||
| 048623 | SB-III 50 460V Phase Indicator C/S | 3/97 | ||
| 048624 | SB-III 50 460V Phase Correction | 3/97 | ||
| 048625 | SB-III 50 460V Phase Correction C/S | 3/97 | ||
| 048652 | Aluminum Doors | 9/97 | ||
| 048675 | SB-III Arctic Package | 9/10 | ||
| 048745 | Battery Cable | 9/10 | ||
| 048746 | Battery Cable | 9/10 | ||
| 092315 | Simpson Leads | 2/95 | ||
| 092852 | Frost Plug Heater | 2/95 | ||
| 093016 | Temperature Sensor | 9/10 | ||
| 709951 | Fuel Tank Kit - 30/50 Gallon 18 Inch Diameter | 2/95 | ||
| 710270 | Fuel Tank Kit - 30/50 Gallon 22 Inch Diameter | 2/95 | ||
| 710278 | Fuel Tank Kit - 75/120 Gallon 22 Inch Diameter | 2/95 | ||
| 711058 | Integral Fuel Tank - SB-II | 2/95 | ||
| 713586 | Indicator Lights - SB-III SR MP IV | 2/95 | ||
| 714181 | Door Switch Kit MP VI | 2/95 | ||
| 714567 | Fuel Tank - 50 Gallon 22 Inch Diameter | 2/95 | ||
| 714701 | Remote Lights Box Kit - SB-III SR+ MP IV+ | 2/95 |
