Установкa Thermo King SB-III CR схема REFRIGERATION COMPONENTS – 167C1
Обновление от: 3/25/03
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 12-740 | TANK - CO2 (104 gallon, see 167B3) | 1 | |
| 2 | 61-949 | TUBE - tank to filter | 1 | |
| 55-302 | NUT - flare | 1 | ||
| 55-6837 | SHOULDER - o-ring | 1 | ||
| 55-6838 | NUT - shoulder | 1 | ||
| 3 | 61-950 | FILTER - CO2 | 1 | |
| 4 | 55-2192 | HANGER - filter | 1 | |
| 55-2969 | SCREW - hanger | 1 | ||
| 55-3089 | SCREW - filter | 1 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 55-4954 | NUT | 2 | ||
| 5 | 92-1348 | BRACKET - expansion valve | 1 | |
| 55-2957 | SCREW - bracket | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-8979 | INSERT | 2 | ||
| 6 | 92-1347 | CLAMP - expansion valve (plastic) | 1 | |
| 92-1349 | CLAMP - expansion valve (metal) | 1 | ||
| 55-3344 | SCREW - clamp | 2 | ||
|
20-55-3344 | Болт | 520 ₽ |
|
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 7 | 61-965 | TUBE - filter to valve | 1 | |
| 55-6357 | SHOULDER - o-ring | 1 | ||
| 55-6358 | NUT - shoulder | 1 | ||
| 8 | 61-955 | VALVE - expansion, electronic | 1 | |
| 61-966 | TUBE - tee to valve | 1 | ||
| 55-373 | NUT - flare | 1 | ||
| 9 | 61-951 | TUBE - valve to tee | 1 | |
| 55-4131 | ADAPTER | 1 | ||
| 10 | 55-2296 | TEE (1/2 x 1/2 x 1/2) | 1 | |
| 11 | 61-967 | TUBE - tee to cool valve (liquid) | 1 | |
| 55-1483 | ELBOW (1/2 sld, 1/2 sld) | 1 | ||
| 12 | 61-1048 | TUBE - liquid, heat valve to tee | 1 | |
| 13 | 66-8729 | VALVE - cool & heat (PV-1 & PV-2, see 171B4) | 2 | |
| 14 | 61-954 | TUBE - valve to tee | 1 | |
| 15 | 61-956 | TUBE - evap inlet | 1 | |
| 16 | 61-962 | TUBE - heater outlet (see 167B9) | 1 | |
| 17 | 55-9749 | TEE (fl x fl x fl) | 1 | |
| 18 | 61-973 | TUBE - vapor line | 1 |
