Установкa Thermo King SB-II w/di 2.2 Engine схема ELECTRICAL COMPONENTS (SB-II TC) – 87F9
Обновление от: 6/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-2823 | SOLENOID - defrost (see 66B11) | 1 | |
|
10-44-2823 | Соленоид оборотов двигателя | 5 370 ₽ |
|
| 44-2756 | DIODE (silicone) | 1 | ||
|
10-44-2756 | Диод соленоида тяги | 1 920 ₽ |
|
| 2 | 66-3693 | VALVE - solenoid (TC unit) | 1 | |
| 3 | 44-6018 | THERMOSTAT - block sensor (Cycle Sentry) | 1 | |
| 30-44-6018 | Выключатель температурный | 15 030 ₽ |
|
|
| 55-3134 | SCREW - thermostat | 2 | ||
| 99-8592 | PLATE - switch | 1 | ||
| 4 | 44-6019 | BOLT - thermistor (Cycle Sentry) | 1 | |
|
10-44-6019 | Термистор | 4 880 ₽ |
|
| 55-4998 | SCREW - plate | 1 | ||
| 55-4613 | FLATWASHER | 1 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 5 | 44-3627 | SWITCH - high temperature cutout | 1 | |
| 55-4507 | SCREW - switch | 2 | ||
| 55-2201 | FLATWASHER | 2 | ||
| 6 | 44-6735 | HARNESS - main | 1 | |
| 7 | 41-1514 | SWITCH - defrost termination | 1 | |
|
10-41-1514 | Датчик окончания оттайки | 14 220 ₽ |
|
| 55-4507 | SCREW - switch | 3 | ||
| 55-2201 | FLATWASHER | 3 | ||
| 55-3800 | LOCKWASHER | 1 | ||
| 8 | 41-2195 | ALTERNATOR (37 amp, model 8MR) | 1 | |
|
10-41-2195 | Генератор 37A, MD/RD/TD-II / SB-II/III | 19 510 ₽ |
|
| 44-8104 | HARNESS - alternator | 1 | ||
| 9 | 44-6534 | SENSOR - radiator | 1 | |
|
10-44-6534 | Сенсор радиатора | 8 830 ₽ |
|
| 10 | 66-2009 | VALVE - pilot solenoid | 1 | |
|
10-66-2009 | Управляющий клапан, KD/MD/TD/RD-II / SB-I/II/III | 18 500 ₽ |
|
| 44-3803 | COIL - solenoid (3/8 bore) | 1 | ||
| 41-1525 | COIL - valve (7/16 bore) | 1 | ||
|
10-41-1525 | Катушка соленоида, 12V 8W | 15 030 ₽ |
|
| 55-8786 | NUT - valve | 1 | ||
| 11 | 44-6493 | HARNESS (Cycle Sentry) | 1 | |
| 12 | 66-4637 | VALVE - solenoid (hot gas, TC unit, see 116G12) | 1 | |
| 13 | 44-6551 | SWITCH - micro (2 speed fan transmission) | 1 | |
| 14 | 44-3018 | SWITCH - water temperature | 1 | |
|
10-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 5 830 ₽ |
|
| PP-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 2 200 ₽ |
|
|
| 15 | 41-7370 | GLOW PLUG | 4 | |
|
10-41-7370 | Свеча накаливания, Isuzu 2.2 DI (D201), SB/SB-II/SB-III/SMX/SMX-II | 2 000 ₽ |
|
| 16 | 44-6602 | CONNECTOR - glow plug | 1 | |
| 17 | 33-628 | GROMMET - control box | 1 | |
| 18 | 44-7997 | TERMINAL - battery (see 84D13) | 1 | |
| 19 | 44-6698 | CABLE - battery (19 in lg) | 2 | |
| 44-6699 | CABLE - battery (22 in lg, for batteries w/ threaded posts, see 84D13) | 2 | ||
| 44-7051 | BOOT - battery cable cover (red) | 1 | ||
| 44-7828 | BOOT - battery cable cover (black) | 1 | ||
| 20 | 44-6741 | CABLE - starter | 1 | |
| 21 | 44-4774 | SWITCH - oil pressure | 1 | |
|
10-44-4774 | Выключатель давления масла | 5 530 ₽ |
|
| 22 | 45-2325 | STARTER | 1 | |
| 23 | 44-9298 | SENSOR - rpm (Cycle Sentry) | 1 | |
|
10-44-9298 | Датчик оборотов двигателя | 14 400 ₽ |
|
|
PP-44-9298 | Датчик оборотов двигателя | 2 760 ₽ |
|
| 44-7620 | BOOT - rpm sensor | 1 | ||
| 24 | 41-3670 | SWITCH - hpco | 1 | |
| 25 | 44-6544 | SOLENOID - engine (see 70B6) | 1 | |
|
10-44-6544 | Соленоид оборотов двигателя, MD-II/KD-II/SB-II/SB-III | 19 090 ₽ |
|
|
PP-44-6544 | Соленоид оборотов двигателя, MD-II/KD-II/SB-II/SB-III | 7 150 ₽ |
|
| 44-2756 | DIODE (silicone) | 1 | ||
|
|
10-44-2756 | Диод соленоида тяги | 1 920 ₽ |
|
| 26 | 44-6545 | SWITCH - air pressure (see 86A5) | 1 | |
|
P-12-01039-08 | Выключатель размораживания, Maxima/Supra/ Vector 1350/1550/18XX/19XX | 16 490 ₽ |
|
