Установкa Thermo King SB-330 & SB-330 RR 30 схема TracKing SB w/ SR-3 CONTROLLER – 250A1
Обновление от: 4/10/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 40-1088 | KIT - TracKing (GPRS SB SR-3 controller) | 1 | ||
| 1 | 41-9902 | ANTENNA & HARNESS | 1 | |
| 2 | 92-6747 | BRACKET - antenna | 1 | |
| 203-500 | TAPE - bracket | A/R | ||
| 55-2977 | SCREW - bracket (sheet metal) | 2 | ||
| 55-9756 | RIVET - bracket | 2 | ||
| 3 | 41-9516 | MODULE - TracKing | 1 | |
| 55-5754 | NUT - module | 2 | ||
| 55-1266 | FLATWASHER | 2 | ||
| 4 | 92-8525 | BRACKET - module | 2 | |
| 203-500 | TAPE - bracket | A/R | ||
| 55-6477 | STUD | 3 | ||
| 203-498 | WIPE (alcohol) | 1 | ||
| 5 | 41-9518 | HARNESS - module to pc board | 1 | |
| 6 | 41-9118 | PLUG (7-pin) | 1 | |
| 41-9121 | SOCKET (20 awg) | 6 | ||
| 7 | 41-9119 | PLUG (5-pin) | 1 | |
| 41-9121 | SOCKET (20 awg) | 3 | ||
| 8 | 44-4653 | TERMINAL - fork (red #10, 16-22 ga) | 1 | |
| 9 | 41-5710 | PLUG - sealed (4-pin) | 1 | |
| 33-3909 | GASKET (4-pin) | 1 | ||
| 41-5719 | SOCKET - gold (16-20 ga) | 2 | ||
| 41-6256 | SEAL - wire | 2 | ||
| 41-9120 | SEAL - cavity (plug) | 2 | ||
| 10 | 41-5709 | PLUG - sealed (8-pin) | 1 | |
| 33-3908 | GASKET (8-pin) | 1 | ||
| 41-5719 | SOCKET - gold (16-20 ga) | 3 | ||
| 41-6256 | SEAL - wire | 3 | ||
| 41-9120 | SEAL - cavity (plug) | 5 | ||
| 11 | 44-9544 | RECEPTACLE (3-pin) | 1 | |
| 44-9545 | WEDGE | 1 | ||
| 44-9591 | TERMINAL - pin (18 ga) | 3 |
