Установкa Thermo King SB-330 & SB-330 RR 30 схема FUEL FILTER & HOSES – 247F6
Обновление от: 7/12/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 11-9015 | HEAD - fuel filter | 1 | |
| 55-5078 | NUT | 2 | ||
| 55-402 | FLATWASHER | 2 | ||
| 2 | 11-9017 | SPUD - fuel filter | 1 | |
| 3 | 11-9016 | SHAFT - water bleed | 1 | |
| 4 | 11-9954 | FILTER - fuel (5 micron, EMI 3000) | 1 | |
| 11-9954 | FILTER - fuel (5 micron, case of 12, EMI 3000) | 1 | ||
| 5 | 11-5320 | ELBOW - hose (1/4) | 3 | |
| 6 | 10-243 | KIT - sleeve & eyelet (1/4) | 5 | |
| 7 | 11-4841 | NUT - hose (1/4) | 5 | |
| 8 | 11-4367 | HOSE (1/4 od x 35 ft lg) | A/R | |
| 9 | 11-4380 | ELBOW - hose fitting (3/8) | 1 | |
|
P-40-00342-02 | Фитинг топливной магистрали | 1 040 ₽ |
|
| 10 | 10-242 | KIT - sleeve & eyelet (3/8) | 4 | |
|
|
P-40-00342-02 | Фитинг топливной магистрали | 1 040 ₽ |
|
| 11 | 11-4941 | NUT - hose (3/8) | 4 | |
| 12 | 11-4372 | HOSE (3/8 od x 35 ft lg) | A/R | |
| 13 | 101-362 | PUMP - fuel injection (see 204G2, TK486V, 2200 rpm) | 1 | |
| 101-354 OEM | Плунжерная пара ТНВД, Yanmar 486V, SB/SLe/SLX/SLXe | 86 500 ₽ |
|
|
| 10-101-354 | Плунжерная пара ТНВД, Yanmar 486V, SB/SLe/SLX/SLXe | 36 470 ₽ |
|
|
| 101-354 | PUMP - fuel injection (see 205C5, TK486VH, 2600 rpm) | 1 | ||
| 101-354 OEM | Плунжерная пара ТНВД, Yanmar 486V, SB/SLe/SLX/SLXe | 86 500 ₽ |
|
|
| 10-101-354 | Плунжерная пара ТНВД, Yanmar 486V, SB/SLe/SLX/SLXe | 36 470 ₽ |
|
|
| 14 | 11-7433 | PUMP - fuel (see 142F8) | 1 | |
|
11-7433 OEM | Топливный насос подкачки, SB/SB-III/SMX/SMX-II/SL/SLe/SLX/SLXe | 24 100 ₽ |
|
|
PP-11-7433 | Топливный насос подкачки, SB/SB-III/SMX/SMX-II/SL/SLe/SLX/SLXe | 6 680 ₽ |
|
| 15 | 91-8732 | BRACKET - fuel filter | 1 | |
| 55-129 | SCREW - bracket | 2 | ||
| 55-402 | FLATWASHER | 4 | ||
| 55-5078 | NUT | 2 | ||
| 16 | 55-4203 | CLAMP - hose (5/8) near flywheel housing | 1 | |
| 55-3644 | CLAMP - hose (1.0) near throttle solenoid | 1 | ||
| 55-3065 | CLAMP - hose (0.5) vertical channel behind engine | 1 | ||
| 55-5424 | SCREW - clamp (M8) | 1 | ||
| 55-7727 | LOCKWASHER | 1 | ||
| 55-7069 | FLATWASHER | 1 | ||
| 55-145 | SCREW - clamp (1/4-20) | 3 | ||
| 55-411 | FLATWASHER | 3 | ||
| 55-366 | LOCKWASHER | 2 | ||
| 55-4118 | NUT | 1 | ||
| 17 | 10-342 | KIT - check valve (fuel line) | 1 | |
| 11-9245 | VALVE - check | 1 | ||
| 18 | 92-2747 | BRACKET - fuel line | 1 | |
| 55-538 | SCREW - bracket | 1 | ||
| 55-411 | FLATWASHER | 1 | ||
| 55-366 | LOCKWASHER | 1 | ||
| 19 | 11-6861 | FITTING - hose (1/4) | 1 | |
| 20 | 11-6862 | FITTING - hose (3/8) | 1 | |
| 21 | 33-316 | GROMMET - fuel lines | 1 | |
| 22 | 10-436 | KIT - pre-strainer | 1 | |
| 23 | 10-458 | KIT - bowl & seal | 1 | |
| 24 | 13-1109 | BOWL - pre-strainer | 1 | |
| 55-3048 | SCREW - pre-strainer | 2 | ||
| 55-375 | LOCKWASHER | 2 | ||
| 55-402 | FLATWASHER | 2 | ||
| 25 | 13-448 | JOINT - banjo (fuel out, FI pump) | 1 | |
| 26 | 13-128 | JOINT - banjo (fuel in, fuel pump) | 1 | |
| 27 | 13-127 | JOINT - banjo (fuel out, fuel pump) | 1 | |
| 28 | 13-446 | JOINT - banjo (fuel in, FI pump) | 1 |
