Установкa Thermo King SB-330 & SB-330 RR 30 схема FUEL FILTER, HEATER & HOSES (RR) – 246C7
Обновление от: 3/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 12-945 | FUEL FILTER/HEATER | 1 | |
| 2 | 11-9953 | FILTER - fuel (inc vent, collar & o-rings) | 1 | |
| 3 | 41-9519 | HEATER - fuel | 1 | |
| 4 | 33-5130 | O-RING - set fittings (7 pcs) | 1 | |
| 5 | NSS | ADAPTER (3/8 nptf to 7/8-14 male) | 2 | |
| 6 | 13-1100 | VALVE - drain | 1 | |
| 7 | 13-1101 | CAP - vent | 1 | |
| 33-4690 | O-RING - cap | 1 | ||
| 55-5078 | NUT | 2 | ||
| 55-402 | FLATWASHER | 2 | ||
| 8 | 13-1084 | SEPERATOR - air/fuel | 1 | |
| 9 | 11-4370 | CONNECTOR - hose (1/4) | 1 | |
| 10 | 11-5665 | TEE - hose (1/4) | 1 | |
| 11 | 13-1107 | FITTING - hose (3/8) | 2 | |
| 12 | 11-5437 | CONNECTOR - hose (3/8) | 1 | |
| 13 | 10-243 | KIT - sleeve & eyelet (1/4) | 6 | |
| 11-4841 | NUT - hose (1/4) | 6 | ||
| 14 | 11-4367 | HOSE (1/4 od x 35 ft lg) | A/R | |
| 15 | 10-242 | KIT - sleeve & eyelet (3/8) | 6 | |
|
P-40-00342-02 | Фитинг топливной магистрали | 1 040 ₽ |
|
| 11-4941 | NUT - hose (3/8) | 6 | ||
| 16 | 11-4372 | HOSE (3/8 od x 35 ft lg) | A/R | |
| 17 | 101-362 | PUMP - fuel injection (see 204G2, TK486V, 2200 rpm) | 1 | |
| 101-354 OEM | Плунжерная пара ТНВД, Yanmar 486V, SB/SLe/SLX/SLXe | 92 440 ₽ |
|
|
| 10-101-354 | Плунжерная пара ТНВД, Yanmar 486V, SB/SLe/SLX/SLXe | 36 470 ₽ |
|
|
| 18 | 11-7433 | PUMP - fuel (see 142F8) | 1 | |
|
11-7433 OEM | Топливный насос подкачки, SB/SB-III/SMX/SMX-II/SL/SLe/SLX/SLXe | 24 100 ₽ |
|
|
PP-11-7433 | Топливный насос подкачки, SB/SB-III/SMX/SMX-II/SL/SLe/SLX/SLXe | 6 680 ₽ |
|
| 19 | 55-4203 | CLAMP - hose (5/8) | 1 | |
| 20 | 33-316 | GROMMET - fuel hoses | 1 | |
| 21 | 11-6837 | CONNECTOR (1/4) | 1 | |
| 22 | 55-4515 | CONNECTOR (3/8) | 1 | |
| 23 | 12-944 | TANK - fuel 156 gal (see 247C6) | 1 | |
| 12-956 | TANK - fuel 156 gal (see 247C6) | 1 | ||
| 12-949 | TANK - fuel 120 gal (see 247C6) | 1 | ||
| 12-955 | TANK - fuel 120 gal (see 247C6) | 1 | ||
| 24 | 41-9570 | HARNESS - fuel heater | 1 | |
| 25 | 41-1276 | HOLDER - fuse | 1 | |
| 41-506 | FUSE - 3 amp | 1 | ||
| 26 | 204-1941 | TOOL - fuel filter wrench (metal) | 1 | |
| 204-1938 | TOOL - fuel filter wrench (plastic) | 1 | ||
| 27 | 92-8545 | BRACKET - fuel filter | 1 | |
| 55-129 | SCREW - bracket | 2 | ||
| 55-402 | FLATWASHER | 4 | ||
| 55-5078 | NUT | 2 |
