Установкa Thermo King SB-310 Tier 2 Engine схема SB-310 30 TIER 2 ENGINE REFERENCE SHEET – 10U12
Обновление от: 7/12/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 920381 | System - SB-310 30 | 3/10 | ||
| 920383 | System - SB-310R 30 | 5/07 | ||
| 002206 | SB-310R 30 Tier 2 | 5/07 | ||
| 002016 | Painted Grille | 3/10 | ||
| 002020 | Chrome Grille | 3/10 | ||
| 002070 | Fresh Air Exchanger | 3/10 | ||
| 002078 | ESOC Fittings | 5/07 | ||
| 002205 | SB-310 30 Tier 2 | 3/10 | ||
| 002110 | Gray Grilles | 5/07 | ||
| 002112 | White Grilles | 5/07 | ||
| 002136 | Fuel Tank - 50 Gallon AL 22 Dia | 5/07 | ||
| 002137 | Fuel Tank - 30 Gallon AL 22 Dia | 5/07 | ||
| 002138 | Fuel Tank - 110 Gallon AL 22 Dia | 5/07 | ||
| 002139 | Fuel Tank - 50 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 5/07 | ||
| 002140 | Fuel Tank - 30 Gallon Aluminum 18 Inch Dia w/ Fuel Level Sensor | 5/07 | ||
| 002141 | Fuel Tank - 50 Gallon Steel 18 Inch Dia w/ Fuel Level Sensor | 5/07 | ||
| 002142 | Fuel Tank - 50 Gallon STL 18 Dia | 5/07 | ||
| 002143 | Fuel Tank - 50 Gallon STL 18 Dia | 5/07 | ||
| 002144 | Fuel Tank - 50 Gallon READY AL | 5/07 | ||
| 002145 | Fuel Tank - 30 Gallon READY AL | 5/07 | ||
| 002146 | Fuel Tank - 50 Gallon AL 22 Dia | 5/07 | ||
| 002147 | Fuel Tank - 30 Gallon AL 22 Dia | 5/07 | ||
| 002148 | Fuel Tank - 110 Gallon AL 22 Dia | 5/07 | ||
| 002149 | Fuel Tank - 50 Gallon AL 18 Dia | 5/07 | ||
| 002150 | Fuel Tank - 30 Gallon AL 18 Dia | 5/07 | ||
| 002151 | Fuel Tank - 50 Gallon 18 Dia R | 5/07 | ||
| 002152 | Fuel Tank - 50 Gallon STL 18 Dia | 5/07 | ||
| 002153 | Fuel Tank - 50 Gallon Steel 18 Inch Dia w/ Fuel Level Sensor | 5/07 | ||
| 002155 | Fuel Tank - 120 Gallon Aluminum | 5/07 | ||
| 002156 | Fuel Tank - 120 Gallon 22 Inch Dia Aluminum | 5/07 | ||
| 002184 | Fuel Tank - 75 Gallon 22 Inch Dia Aluminum | 5/07 | ||
| 002190 | External Battery Cables | 5/07 | ||
| 002191 | Threaded Battery Cables | 5/07 | ||
| 002208 | Fuel Heater - Tier 2 | 3/10 | ||
| 002222 | Fuel Tank - 454 Liter | 3/10 | ||
| 002236 | Tapered Battery Cables | 3/10 | ||
| 002240 | Fuel Tank - 50 Gallon AL 22 Dia | 3/10 | ||
| 002241 | Fuel Tank - 50 Gallon AL 22 Dia | 3/10 | ||
| 002242 | Fuel Tank - 50 Gallon 22 Inch Dia (Alum) | 3/10 | ||
| 002247 | Fuel Tank - 120 Gallon AL 22 Dia | 3/10 | ||
| 002251 | Fuel Tank - 120 Gallon 22 Inch Dia Aluminum | 3/10 | ||
| 048332 | Compound Gauge | 3/10 | ||
| 048601 | Fuel Tank - 30 Gallon 22 Inch Dia Aluminum | 5/07 | ||
| 048603 | Fuel Tank - 50 Gallon 22 Inch Dia Aluminum | 5/07 | ||
| 048602 | Fuel Tank - 50 Gallon 22 Inch Dia Aluminum | 5/07 | ||
| 048660 | Alternator - 65 Amp | 3/10 | ||
| 048678 | Frost Plug Heater | 3/10 | ||
| 048725 | Fuel Tank - 50 Gallon Aluminum 18 Inch Dia Aluminum | 5/07 | ||
| 048776 | Fuel Tank - 110 Gallon 22 Inch Dia Aluminum | 5/07 | ||
| 720172 | Dual Remote Lights | 5/07 | ||
| 700250 | Door Switch | 3/10 | ||
| 700248 | ERC-1 | 3/10 | ||
| 700252 | Flushmount Remote Controller | 3/10 | ||
| 714134 | ERC-1 | 5/07 | ||
| 714567 | Fuel Tank - 50 Gallon 22 Inch Diameter | 5/07 | ||
| 715581 | Dual Door Switch | 5/07 | ||
| 715587 | Fuel Tank Kit | 5/07 | ||
| 715589 | Remote Status Light Kit | 5/07 | ||
| 720063 | Fuel Level Sensor Kit | 3/10 | ||
| 720491 | HMI Sensor - 10 ft | 3/10 | ||
| 720492 | HMI Sensor - 20 ft | 3/10 | ||
| 720493 | HMI Sensor - 40 ft | 3/10 | ||
| 720494 | HMI Sensor - 60 ft | 3/10 | ||
| 720495 | HMI Sensor - 80 ft | 3/10 | ||
| 720705 | Kit - Trac-King 2-Way SR-2 Rail | 5/07 | ||
| 720716 | Kit - Trac-King 2-Way SR-2 Trailer | 5/07 | ||
| 720717 | Kit - Trac-King 1-Way SR-2 Trailer | 5/07 | ||
| 720718 | Kit - Trac-King 1-Way SR-2 3rd Party | 3/10 | ||
| 720724 | Kit - RCOM II SR-2 | 3/10 | ||
| 720840 | Kit - Fuel Level Sensor - 22 Inch | 3/10 | ||
| 720841 | Kit - Fuel Level Sensor - 18 Inch | 3/10 | ||
| 811053 | Kit - Installation Box | 3/10 |
