Установкa Thermo King SB-300 30 схема ENGINE COOLING SYSTEM – 158G6
Обновление от: 2/6/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | TANK - expansion (see note) | 1 | |
| 55-101 | SCREW - tank | 4 | ||
| 55-366 | LOCKWASHER | 4 | ||
| 55-411 | FLATWASHER | 4 | ||
| 55-2699 | LOCKWASHER (internal/external tooth) | 4 | ||
| 2 | 11-5406 | CAP - radiator | 1 | |
|
10-11-5406 | Крышка радиатора | 2 200 ₽ |
|
| 3 | 99-1655 | HOSE - overflow | 1 | |
| 55-2796 | CLAMP - hose | 1 | ||
| 4 | 41-2842 | SENSOR - coolant level | 1 | |
| 55-4560 | NUT - sensor | 1 | ||
| 55-2996 | LOCKWASHER | 1 | ||
| 55-2001 | FLATWASHER | 1 | ||
| 5 | 99-1655 | HOSE - bleed | 1 | |
| 6 | 55-6726 | CLAMP - hose (EPDM) | 2 | |
| 55-1521 | CLAMP - hose (silicone) | 2 | ||
| 7 | 67-1743 | COIL - condenser/radiator (SB-300 before 8/01) | 1 | |
| 67-2219 | COIL - condenser/radiator (SB-300 8/01 & after, SB-310) | 1 | ||
| 67-2218 | COIL - condenser/radiator (SB-110/210, DE) | 1 | ||
| 67-2221 | COIL - condenser (SB-110/210, vinyl dipped) | 1 | ||
| 8 | 55-2818 | CLAMP - hose (EPDM) | 6 | |
| 55-3401 | CLAMP - hose (silicone) | 6 | ||
| 9 | 55-5074 | CLAMP - hose (EPDM) | 2 | |
| 55-1521 | CLAMP - hose (silicone) | 2 | ||
| 10 | 98-796 | HOSE - radiator to tank (EPDM, cut to 5.25 in) | 1 | |
| 12-383 | HOSE - radiator (silicone, cut to 5.25 in) | 1 | ||
| 11 | 11-9297 | TUBE - engine to radiator (before 3/01) | 1 | |
| 11-9561 | TUBE - engine to radiator (3/01 & after) | 1 | ||
| 12 | 11-9505 | HOSE - tube to engine (EPDM) | 2 | |
| 11-9506 | HOSE - tube to engine (silicone) | 2 | ||
| 13 | 11-8480 | HOSE - tube to engine (EPDM, cut to 4.0 in) | 2 | |
| 12-537 | HOSE - tube to engine (silicone, cut to 4.0 in) | 2 | ||
| 14 | 13-509 | PUMP - water (ELC compatible, see 149C12) | 1 | |
| 10-13-2572 | Водяной насос, Yanmar TK 482 / 486 / 486V | 37 520 ₽ |
|
|
| 10-13-2268 | Водяной насос, Yanmar TK 482 / 486 / 486V | 26 160 ₽ |
|
|
|
PP-13-2268 | Водяной насос, Yanmar TK 482 / 486 / 486V | 8 320 ₽ |
|
|
PP-13-509 | Водяной насос, Yanmar TK 482 / 486 / 486V | 7 900 ₽ |
|
| 15 | 13-959 | TUBE - engine to radiator | 1 | |
| 16 | 91-2473 | CLAMP (1-1/8 dia) | 2 | |
| 55-4811 | SCREW - clamp (ss) | 2 | ||
| 55-5677 | SCREW (hh, 1/4-20, steel) | 2 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-4953 | NUT | 2 | ||
| 55-8711 | SCREW (hh, 1/4-20, brass) | 2 | ||
| 17 | 55-3026 | CLAMP (5/8 dia) | 1 | |
| 18 | 55-9279 | FITTING - elbow (units w/ screw compressors) | 1 | |
| 19 | 11-9225 | HOSE | 1 | |
| 20 | 92-4378 | BRACKET - radiator support (w/ threaded inserts) | 1 | |
| 21 | 92-2723 | BRACKET - hose support (SB 50s) | 1 | |
| 55-7004 | SCREW - bracket | 2 | ||
| 55-7072 | FLATWASHER | 2 | ||
| 22 | 10-359 | KIT - expansion tank | 1 | |
| 12-842 | TANK - expansion | 1 | ||
|
10-12-842 | Расширительный бак | 38 500 ₽ |
|
| 23 | 11-9632 | CAP - tank | 1 | |
|
10-11-9632 | Крышка расширительного бачка, SLX/SLXe | 930 ₽ |
|
| 24 | 41-6217 | SWITCH - sensor | 1 | |
| 25 | 41-5650 | HARNESS - coolant level switch | 1 | |
| 26 | 41-5066 | SENSOR - water temperature | 1 | |
|
10-41-6539 | Датчик температуры двигателя Yanmar 370 / 374 / 376 / 395 / 482 / 486 / 486V | 8 970 ₽ |
|
|
PP-41-6539 | Датчик температуры двигателя Yanmar 370 / 374 / 376 / 395 / 482 / 486 / 486V | 2 720 ₽ |
|
