Установкa Thermo King SB-300 30 схема ALTERNATOR MOUNTING (TK486 & TK482 w/ LOW MOUNT WATER PUMP) – 151A14
Обновление от: 12/3/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-9007 | BRACKET - alternator | 1 | |
| 92-3868 | BRACKET - alternator (5/00 & after) | 1 | ||
| 2 | 91-9008 | BRACKET - alternator adjusting | 1 | |
| 92-3866 | BRACKET - alternator adjusting (5/00 & after) | 1 | ||
| 3 | 91-9009 | BRACKET - alternator secondary | 1 | |
| 4 | 78-1341 | BELT | 1 | |
| 10-78-1341 | Ремень водяной помпы и генератора, SB-XXX/SB-III | 3 080 ₽ |
|
|
| PP-78-1341 | Ремень водяной помпы и генератора, SB-XXX/SB-III | 1 600 ₽ |
|
|
| 5 | 55-5419 | SCREW - alternator to bracket (M10 x 70) | 1 | |
| 6 | 55-5424 | SCREW (M8 x 25) | 2 | |
| 7 | 55-4680 | SCREW (M10 x 35) | 3 | |
| 8 | 55-6215 | SCREW (M8 x 30) | 1 | |
| 9 | 55-7167 | SCREW (M8 x 55) | 1 | |
| 10 | 55-4621 | NUT | 1 | |
| 11 | 55-4931 | SPACER | 1 | |
| 12 | 55-1173 | LOCKWASHER (M10) | 1 | |
| 13 | 55-4613 | FLATWASHER (M8) | 3 | |
| 14 | 55-790 | LOCKWASHER (M8) | 5 | |
| 15 | 55-7072 | FLATWASHER (M10) | 1 | |
| 16 | 55-5932 | SCREW - alternator adjust (M8) | 1 | |
| 17 | 55-2769 | WASHER - special | 2 |
