Установкa Thermo King SB-190 30 схема ENGINE COOLING SYSTEM – 166C6
Обновление от: 8/26/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 10-359 | KIT - expansion tank | 1 | |
| 12-842 | TANK - expansion | 1 | ||
|
10-12-842 | Расширительный бак | 38 500 ₽ |
|
| 55-145 | SCREW - tank | 4 | ||
| 55-366 | LOCKWASHER | 4 | ||
| 55-411 | FLATWASHER | 4 | ||
| 55-6526 | INSERT | 4 | ||
| 2 | 11-5406 | CAP - radiator | 1 | |
|
10-11-5406 | Крышка радиатора | 2 200 ₽ |
|
| 3 | 99-1655 | HOSE - overflow | 1 | |
| 4 | 41-1818 | SENSOR - coolant level | 1 | |
| 41-1818 OEM | Датчик уровня охлаждающей жидкости | 13 580 ₽ |
|
|
| 55-4560 | NUT - terminal | 1 | ||
| 55-2996 | LOCKWASHER | 1 | ||
| 55-2001 | FLATWASHER | 1 | ||
| 5 | 11-8050 | HOSE - bleed | 1 | |
| 6 | 55-2796 | CLAMP - hose | 4 | |
| 7 | 67-2218 | COIL - condenser/radiator (see 173A4) | 1 | |
| 8 | 55-3401 | CLAMP - hose | 6 | |
| 9 | 55-6726 | CLAMP - hose | 2 | |
| 10 | 12-537 | HOSE - radiator to tank (silicone, cut to 6.0 in) | 1 | |
| 11 | 11-7998 | TUBE - radiator | 1 | |
| 12 | 91-2473 | CLAMP - tube | 4 | |
| 55-349 | SCREW - clamp | 4 | ||
| 55-411 | FLATWASHER | 4 | ||
| 55-366 | LOCKWASHER | 4 | ||
| 55-4118 | NUT | 4 | ||
| 13 | 91-6158 | PLATE - clamp | 2 | |
| 14 | 11-9356 | PUMP - coolant (see 100C10) | 1 | |
|
US-11-9356 | Водяной насос, Isuzu 2.2 (D201), SB-II/III / SMX/SMX-II | 10 780 ₽ |
|
|
PP-11-9356 | Водяной насос, Isuzu 2.2 (D201), SB-II/III / SMX/SMX-II | 4 670 ₽ |
|
| 15 | 55-1521 | CLAMP - hose (silicone) | 2 | |
| 16 | 11-5932 | HOSE - bypass (silicone) | 1 | |
| 17 | 55-5094 | DRAIN COCK | 1 | |
| 18 | 33-487 | GASKET - thermostat | 1 | |
|
10-33-487 | Прокладка термостата, Isuzu 2.2, SB-I/II/III / SMX/SMX-II | 910 ₽ |
|
| 19 | 11-7702 | THERMOSTAT - coolant | 1 | |
|
11-7702 OEM | Термостат Isuzu 2.2, SB-I/II/III / SMX/SMX-II | 3 830 ₽ |
|
|
10-11-7702 | Термостат Isuzu 2.2, SB-I/II/III / SMX/SMX-II | 1 790 ₽ |
|
| 20 | 11-3346 | ADAPTER - water outlet | 1 | |
| 55-5424 | SCREW - adapter | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 21 | 11-9552 | HOSE - radiator to engine | 1 | |
| 22 | 11-9574 | HOSE - engine to tube | 2 | |
| 23 | 11-9584 | TUBE - engine to radiator | 1 | |
| 24 | 92-4378 | BRACKET - tube | 1 | |
| 55-1587 | SCREW - bracket | 2 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-4953 | NUT | 2 |
