Установкa Thermo King RT-II Series схема POWER PACK CONTROL BOX – 131E2
Обновление от: 8/22/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-7288 | BOX - control | 1 | |
| 2 | 91-5157 | PLATE - rear | 1 | |
| 55-2995 | SCREW - plate | 10 | ||
| 55-2001 | FLATWASHER | 20 | ||
| 55-2964 | LOCKWASHER | 10 | ||
| 55-2965 | NUT | 10 | ||
| 3 | 55-3000 | SCREW - ground | 2 | |
| 55-3496 | LOCKWASHER (internal/external) | 2 | ||
| 55-2996 | LOCKWASHER (internal tooth) | 4 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-2965 | NUT | 2 | ||
| 4 | 41-3990 | SOLENOID (12VDC) | 2 | |
| 55-3018 | SCREW - solenoid | 4 | ||
|
20-55-3018 | Болт | 540 ₽ |
|
| 55-2086 | FLATWASHER | 8 | ||
| 55-2993 | LOCKWASHER | 4 | ||
| 55-1801 | NUT | 4 | ||
| 5 | 44-5537 | SOCKET - relay | 3 | |
| 55-2995 | SCREW - socket | 2 | ||
| 55-3008 | WASHER - sealing | 2 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2965 | NUT | 2 | ||
| 6 | 44-9112 | RELAY - mini | 2 | |
| 7 | 41-1578 | BOARD - terminal | 1 | |
| 55-4487 | SCREW - board | 2 | ||
| 55-3014 | LOCKWASHER | 2 | ||
| 55-3013 | FLATWASHER | 2 | ||
| 55-2999 | NUT | 2 | ||
| 8 | 91-6723 | MARKSTRIP | 1 | |
| 9 | 44-8765 | DIODE | 3 | |
| 10 | 44-3651 | CONNECTOR - liquid tite | 3 | |
| 55-2653 | LOCKNUT | 3 | ||
| 11 | 41-1579 | HARNESS - main control | 1 | |
| 12 | 91-7289 | COVER - control box | 1 | |
| 99-7246 | STRIP - gasket (25 ft) | A/R | ||
| 13 | 55-2957 | SCREW - cover | 2 | |
| 55-2993 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-2658 | RECEPTACLE - floating | 2 | ||
| 14 | 40-1082 | SWITCH - only | 1 | |
|
10-44-7774 | Тепловой предохранитель, SB-I/II/III / SMX | 12 430 ₽ |
|
| 44-1556 | RESISTOR - switch | 1 | ||
|
10-44-1556 | Резистор теплового реле, 12V 5Ω | 1 230 ₽ |
|
| 44-2119 | SEAL - pushbutton | 1 | ||
| 55-3022 | SCREW - switch | 2 | ||
| 55-2201 | FLATWASHER | 2 | ||
| 55-2202 | LOCKWASHER | 2 | ||
| 55-4510 | WASHER - retaining | 2 | ||
| 15 | 44-490 | SWITCH - on/off | 1 | |
|
10-44-490 | Выключатель | 2 590 ₽ |
|
| 44-739 | BOOT - switch | 1 | ||
| 16 | 44-5703 | HOURMETER | 1 | |
|
10-44-5703 | Счетчик часов | 6 030 ₽ |
|
| 55-3256 | SCREW - hourmeter | 2 | ||
| 55-3013 | FLATWASHER | 2 | ||
| 55-3014 | LOCKWASHER | 2 | ||
| 55-2999 | NUT | 2 | ||
| 17 | 99-1739 | NAMEPLATE - cover | 1 | |
| 18 | 44-4238 | BREAKER - circuit (20 amp) | 2 | |
| 55-2995 | SCREW - circuit breaker | 2 | ||
| 55-2965 | NUT | 4 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 19 | 44-6205 | TIMER | 1 | |
| 55-5070 | SCREW - timer | 1 | ||
| 55-2998 | LOCKWASHER | 1 | ||
| 55-3013 | FLATWASHER | 2 | ||
| 55-2999 | NUT | 1 | ||
| 20 | 44-6021 | RESISTOR (47K ohm) | 1 | |
| 21 | 44-6007 | DIODE | 2 | |
| 22 | 44-9391 | RELAY | 1 | |
|
10-44-9391 | Реле | 3 250 ₽ |
|
| 23 | 44-2739 | NAMEPLATE - Push to Reset | 1 | |
| 24 | 99-3454 | NAMEPLATE - On/Off | 1 | |
| 25 | 91-7290 | MOUNT - vibration | 1 |
