Установкa Thermo King RT-II Series схема CONTROL PANEL – 131C9
Обновление от: 5/29/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-2736 | PANEL - control | 1 | |
| 2 | 44-5560 | BREAKER - circuit (40 amp) | 2 | |
| 3 | 44-5494 | BREAKER - circuit (65 amp) | 1 | |
| 55-103 | SCREW - breaker | 6 | ||
| 55-3233 | LOCKWASHER | 6 | ||
| 4 | 44-7216 | BREAKER - circuit (10 amp) | 1 | |
| 55-759 | SCREW - breaker | 2 | ||
| 55-431 | FLATWASHER | 2 | ||
| 5 | 91-2739 | MARKSTRIP | 1 | |
| 6 | 44-6119 | THERMOSTAT | 1 | |
| 91-2737 | NAMEPLATE - thermostat | 1 | ||
| 55-103 | SCREW - thermostat | 2 | ||
| 55-3233 | LOCKWASHER | 2 | ||
| 7 | 44-1222 | KNOB - thermostat | 1 | |
| 8 | 44-9112 | RELAY - mini | 1 | |
| 9 | 44-5537 | SOCKET - relay | 1 | |
| 44-5763 | DIODE | 1 | ||
| 55-759 | SCREW - socket | 1 | ||
| 55-431 | FLATWASHER | 1 | ||
| 55-2752 | NUT | 1 | ||
| 10 | 41-3987 | SOLENOID | 4 | |
| 44-5763 | DIODE | 3 | ||
| 55-165 | SCREW - solenoid | 8 | ||
| 55-411 | FLATWASHER | 16 | ||
| 55-366 | LOCKWASHER | 8 | ||
| 55-291 | NUT | 8 | ||
| 11 | 91-2740 | NAMEPLATE - EFS | 1 | |
| 91-2741 | NAMEPLATE - ESS1 | 1 | ||
| 91-2742 | NAMEPLATE - CFS | 1 | ||
| 91-2743 | NAMEPLATE - ESS | 1 | ||
| 12 | 55-629 | SCREW - positive | 2 | |
| 13 | 55-629 | SCREW - negative | 1 | |
| 55-8596 | FLATWASHER | 4 | ||
| 55-6904 | WASHER - shoulder | 2 | ||
| 55-3238 | LOCKWASHER | 4 | ||
| 55-277 | NUT | 4 | ||
| 55-698 | LOCKWASHER (internal tooth) | 1 | ||
| 14 | 41-1516 | BOARD - terminal | 1 | |
| 55-2366 | SCREW - board | 2 | ||
| 55-1266 | FLATWASHER | 4 | ||
| 55-3233 | LOCKWASHER | 2 | ||
| 55-3519 | NUT | 2 |
