Установкa Thermo King RLFEA1-M1 схема INVERTER FRAME – 264G4
Обновление от: 2/12/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-653 | FRAME - inverter | 1 | |
| 55-8798 | INSERT (10-32) | 8 | ||
| 55-8711 | INSERT (1/4-20) | 12 | ||
| 55-8979 | INSERT (1/4-20) | 2 | ||
| 2 | 55-3458 | PIN - cotter | 2 | |
| 3 | 33-1809 | GROMMET (.5 id) | 2 | |
| 4 | 33-5067 | GASKET - sight glass | 1 | |
| 5 | 99-6968 | STRIP - neoprene (1.0 in wide x 50 ft) | A/R | |
| 6 | 33-5068 | STRIP - neoprene (1.0 in wide x 10.5 in lg) | 1 | |
| 7 | 93-654 | COVER - inverter radiator | 1 | |
| 55-2957 | SCREW - cover | A/R | ||
| 55-2086 | FLATWASHER | A/R | ||
| 55-1800 | LOCKWASHER | A/R | ||
| 8 | 33-5066 | INSULATION - strip | 2 | |
| 9 | 98-5425 | GUARD - fan | 1 | |
| 10 | 78-1460 | FAN | 1 | |
| 11 | 55-2979 | SCREW - fan & guard | 4 | |
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-4727 | WASHER - special | 4 | ||
| 12 | 93-659 | COVER - inverter opening | 1 | |
| 13 | 33-5069 | GASKET - cover | 1 | |
| 55-2957 | SCREW - cover | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 14 | 93-655 | BRACKET - water pump | 1 | |
| 55-2977 | SCREW - channel | 4 | ||
| 15 | 92-6599 | BRACKET - switch | 1 | |
| 55-3027 | SCREW - bracket | 2 | ||
| 55-4560 | NUT | 2 | ||
| 16 | 41-7998 | SWITCH | 1 | |
| 17 | 92-6600 | MARKSTRIP - Door Switch | 1 | |
| 18 | 92-4932 | PROTECTOR - edge | 1 |
