Установкa Thermo King RLFEA1-M1 схема REFRIGERATION CONDENSER – 262H5
Обновление от: 10/25/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-6289 | TUBE - discharge | 1 | |
| 66-9842 | VALVE | 2 | ||
| 66-4553 | FITTING - saddle | 1 | ||
| 2 | 41-4486 | SWITCH - hpco | 1 | |
| 3 | 41-9043 | TRANSDUCER - discharge | 1 | |
| 4 | 61-6288 | TUBE - discharge, tube to tee | 1 | |
| 5 | 61-3654 | TUBE | 1 | |
| 6 | 55-6174 | TEE (7/8 x 7/8 x 7/8) | 1 | |
| 7 | 61-5121 | TUBE - discharge, tee to condenser (roadside) | 1 | |
| 8 | 66-7392 | VALVE - relief (see 119B8) | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 9 | 67-2499 | COIL - condenser (curbside) | 1 | |
| 10 | 67-2498 | COIL - condenser (roadside) | 1 | |
| 11 | 61-5122 | TUBE - condenser to tee (liquid) | 1 | |
| 12 | 66-9445 | TUBE | 1 | |
| 13 | 55-904 | TEE (5/8 x 5/8 x 5/8) | 1 | |
| 14 | 61-6290 | TUBE - liquid, tee to tube | 1 | |
| 15 | 61-5465 | TUBE - liquid, tube to receiver tank | 1 | |
| 16 | 67-2500 | TANK - receiver (see 244A9) | 1 | |
| 17 | 61-5466 | TUBE - liquid, receiver tank to bushing | 1 | |
| 18 | 306-221 | DEHYDRATOR | 1 | |
| 33-4239 | GASKET - teflon | 2 | ||
| 19 | 66-5946 | VALVE - shutoff | 2 | |
| 20 | 55-5293 | BUSHING | 2 | |
| 21 | 61-5126 | TUBE - bushing to indicator (liquid) | 1 | |
| 22 | 66-2648 | INDICATOR - liquid (sight glass) | 1 | |
| 66-9273 | INDICATOR - dry eye | 1 | ||
| 23 | 61-5215 | TUBE - indicator to valve | 1 | |
| 24 | 91-758 | CLAMP - tube (.625) | 3 | |
| 25 | 92-8417 | BRACKET - condenser tubing | 1 | |
| 26 | 55-7013 | CLAMP - tube (.875) | 1 | |
| 27 | 92-8395 | BRACKET - shut off valve | 1 | |
| 28 | 92-8828 | BRACKET - receiver tank | 1 |
