Установкa Thermo King REH-M6 схема CONDENSER MOTOR & FAN – 248C3
Обновление от: 9/10/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 104-790 | MOTOR - condenser fan | 1 | |
| 2 | 55-2969 | SCREW - motor | 4 | |
| 3 | 55-4184 | LOCKWASHER | 4 | |
| 4 | 55-4954 | NUT | 4 | |
| 5 | 78-1168 | FAN - condenser | 1 | |
| 6 | 91-9741 | CONNECTOR (90 degree) | 1 | |
| 33-4410 | WASHER - sealing | 3 | ||
| 55-2836 | NUT | 5 | ||
| 7 | 41-9559 | HARNESS - condenser motor | 1 | |
| 41-543 | TERMINAL - wirepin (red, 22-18 ga) | 3 | ||
| 44-2791 | TERMINAL - ring (blue #10, 16-14 ga) | 3 | ||
| 8 | 91-9746 | CONNECTOR - straight | 1 | |
| 33-4410 | WASHER - sealing | 1 | ||
| 55-2836 | NUT | 1 |
