Установкa Thermo King REH-M6 схема CONDENSER MOUNTING & CLAMPS – 248B4
Обновление от: 7/29/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR - group (see 248B5) | 1 | |
| 2 | 55-2192 | HANGER - dehydrator | 1 | |
| 55-2969 | SCREW - hanger, mounting | 1 | ||
| 55-2959 | LOCKWASHER | 1 | ||
| 55-2958 | FLATWASHER | 1 | ||
| 55-3121 | SCREW - hanger, clamping | 1 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-4953 | NUT - lock | 1 | ||
| 3 | 91-758 | CLAMP - tube | 5 | |
| 55-3675 | SCREW - clamp | 5 | ||
| 55-2086 | FLATWASHER | 5 | ||
| 55-1800 | LOCKWASHER | 7 | ||
| 55-4953 | NUT - lock | 2 | ||
| 4 | 33-367 | GROMMET (.625 id) | 2 | |
| 5 | 91-9727 | BRACKET - tube | 1 | |
| 55-2957 | SCREW - bracket | 1 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-2086 | FLATWASHER | 1 | ||
| 6 | 67-2524 | COIL - condenser (roadside) | 1 | |
| 7 | 67-2525 | COIL - condenser (curbside) | 1 | |
| 55-2957 | SCREW - condenser coil | 15 | ||
| 55-1800 | LOCKWASHER | 15 | ||
| 55-4414 | WASHER - special | 15 | ||
| 8 | 91-9695 | INSULATION - roadside | 1 | |
| 9 | 91-9696 | INSULATION - curbside | 1 | |
| 10 | 92-8614 | BRACKET - tube support | 1 | |
| 11 | 92-6979 | BRACKET - tube support | 1 | |
| 55-2957 | SCREW - bracket | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 12 | 55-7013 | CLAMP - tube | 2 | |
| 55-3462 | SCREW - clamp | 2 | ||
|
20-55-3462 | Болт | 600 ₽ |
|
| 55-2086 | FLATWASHER | 4 | ||
| 55-4953 | NUT - lock | 2 |
