Установкa Thermo King REH-M5 схема CONDENSER MOTOR/FAN – 228B2
Обновление от: 6/16/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 104-749 | MOTOR - condenser fan (400V) | 1 | |
| 2 | 55-2969 | SCREW - motor | 4 | |
| 3 | 55-4184 | LOCKWASHER | 4 | |
| 4 | 55-4954 | NUT | 4 | |
| 5 | 78-1645 | FAN - condenser | 1 | |
| 6 | 41-8290 | HARNESS - condenser | 1 |
