Установкa Thermo King REH-M2 схема INSULATION – 153G12
Обновление от: 10/29/99
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-9677 | INSULATION - bulkhead | 2 | |
| 2 | 91-9672 | INSULATION - blower floor (curbside) | 1 | |
| 3 | 91-9684 | INSULATION - evaporator (top) | 2 | |
| 4 | 91-9685 | INSULATION (front, curbside) | 1 | |
| 5 | 91-9674 | INSULATION - water dam (top) | 1 | |
| 6 | 91-9676 | INSULATION - drain pan (under coil) | 1 | |
| 7 | 91-9686 | INSULATION (front, middle) | 1 | |
| 8 | 91-9691 | INSULATION - floor (front) | 1 | |
| 9 | 91-9690 | INSULATION - floor (rear) | 1 | |
| 10 | 91-9675 | INSULATION - drain pan (under coil) | 1 | |
| 11 | 91-9673 | INSULATION - water dam (top) | 1 | |
| 12 | 91-9671 | INSULATION - blower floor (roadside) | 1 | |
| 13 | 91-9687 | INSULATION (front, roadside) | 1 | |
| 14 | 91-9688 | INSULATION (rear, roadside) | 1 | |
| 15 | 91-9689 | INSULATION (rear, curbside) | 1 |
