Установкa Thermo King RD-II TLE схема POWER RECEPTACLE GROUP (EMEIA-Z) – 135E3
Обновление от: 5/30/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 99-9845 | BOX - power receptacle | 1 | |
| 2 | 55-7472 | PLUG - button | 2 | |
| 3 | 99-4976 | STRIP - gasket (box) | A/R | |
| 4 | 91-6260 | COVER - box | 1 | |
| 55-2995 | SCREW - cover | 2 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-2965 | NUT | 2 | ||
| 5 | 44-709 | SWITCH - on/off | 1 | |
|
10-44-709 | Выключатель четырехполюсный | 5 130 ₽ |
|
| 6 | 44-9085 | LIGHT - indicator (amber) | 1 | |
| 7 | 44-1936 | SWITCH - diesel/electric | 1 | |
| 8 | 44-739 | BOOT - switch | 2 | |
| 9 | 44-8872 | INDICATOR - phase (380/460V) | 1 | |
| 10 | 41-712 | RECEPTACLE (32 amp, 380V, 5-pin) | 1 | |
| 44-6875 | RECEPTACLE (32 amp, 380V, 4-pin, EMEIA) | 1 | ||
| 11 | 33-1697 | GASKET - receptacle | 2 | |
| 55-8126 | SCREW - receptacle (2-3/4 lg) | 2 | ||
| 55-5698 | SCREW - receptacle (1-1/2 lg) | 2 | ||
| 55-2001 | FLATWASHER | 8 | ||
| 55-2965 | NUT | 4 | ||
| 12 | 99-9052 | COVER - receptacle | 1 | |
| 13 | 41-520 | PLUG - power (380/3/50, mates w/ 41-519) | 1 | |
| 44-6685 | PLUG (380V, 4-pin) | 1 | ||
| 14 | 55-3831 | CONNECTOR - cable | 2 | |
| 15 | 91-6261 | NAMEPLATE - diesel/electric | 1 | |
| 16 | 99-7834 | NAMEPLATE - Caution | 1 | |
| 17 | 41-786 | HARNESS - diesel/electric | 1 | |
| 18 | 44-9199 | CABLE - motor | 1 | |
| 19 | 99-9700 | NAMEPLATE - 380VAC 50 Hz 3 phase | 1 |
